FieldServer FS-8704-13 Driver Manual

Ge-srtp ethernet driver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A Sierra Monitor Company
Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8704-13 GE-SRTP Ethernet Driver
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after January 1, 1999
Instruction Manual Part Number FS-8704-13
Version 1.00
Revision 1.a
9/26/2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-8704-13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FieldServer FS-8704-13

Summary of Contents for FieldServer FS-8704-13

  • Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8704-13 GE-SRTP Ethernet Driver APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after January 1, 1999 Instruction Manual Part Number FS-8704-13 Version 1.00 Revision 1.a 9/26/2002...

  • Page 2: Table Of Contents

    Map Descriptor Example..14 Driver Notes... 15 Driver Stats... 15 Driver Error messages ... 16 Scaling... 17 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com TABLE OF CONTENTS E-mail: support@fieldserver.com Page I...

  • Page 3: Ge-Srtp Driver Description

    FS-8704-13 GE-SRTP 1. GE-SRTP Driver Description The GE-SRTP driver allows the FieldServer to transfer data to and from devices over Ethernet using GE-SRTP Driver protocol. There are two Ethernet ports standard on the FieldServer. The FieldServer can emulate either a Server or Client.

  • Page 4: Driver Scope Of Supply

    RJ45 to DB9F connector adapter RJ45 to DB25M connection adapter RS485 connection adapter Driver Manual. 2.2 Provided by user GE-SRTP System. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com E-mail: support@fieldserver.com Page 2 Driver Manual...

  • Page 5: Hardware Connections

    Make sure the device IP_address is configured to be on the same IP network as on the FieldServer. Use a crossover cable if the FieldServer is connected directly to the PLC device. Use a straight cable if the FieldServer is connected to a hub.

  • Page 6: Configuring The Fieldserver As A Ge-Srtp Driver Client

    This section documents and describes the parameters necessary for configuring the FieldServer to communicate with a GE-SRTP Driver Server. The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable the FieldServer for GE-SRTP Driver communications, the driver independent FieldServer buffers need to be declared in the “Data Arrays”...

  • Page 7: Client Side Connections

    4.4.1 FieldServer Specific Map Descriptor Parameters Column Title Map_Descriptor_Name Data_Array_Name Data_Array_Location Function FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Specify which port the device is connected to the FieldServer Specify protocol used...

  • Page 8: Driver Specific Map Descriptor Parameters

    . (If the Length is 10 then 10 bits are read and each bit is stored in its own location.) 4.4.3 Timing Parameters Column Title Scan_Interval FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Function Rate at which data is polled E-mail: support@fieldserver.com...

  • Page 9: Map Descriptor Example 1 - Simple Read

    CSV file. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Driver Manual element). The PLC is polled every 2 seconds , rdbc , 1.0s...

  • Page 10: Map Descriptor Example 2 - Simple Write

    4.4.5 Map Descriptor Example 2 – Simple Write This example writes data from the Fieldserver data array called DA_AO to the PLC identified as NODE1. The write is repeated every 5 seconds. Ten word values are written to the PLC’s %AQ Data Table starting at location 20.

  • Page 11: Map Descriptor Example 3 - Handling Bits

    %T starting at bit 8. This is most useful when writing to the PLC in cases where you want to turn one particular bit on or off. Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Scan_Interval, node_name, Address, Length, Data_Type, Format Read_DI , DA_T , 100 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Driver Manual , rdbc , 2.0s...

  • Page 12: Configuring The Fieldserver As A Ge-Srtp Driver Server

    This section documents and describes the parameters necessary for configuring the FieldServer to communicate with a GE-SRTP Driver Client The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable the FieldServer for GE-SRTP Driver communications, the driver independent FieldServer buffers need to be declared in the “Data Arrays”...

  • Page 13: Server Side Connections

    Protocol Example Server Side Connections Connections Adapter, Protocol SRTP FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Specify which port the device is connected to the FieldServer Specify protocol used E-mail: support@fieldserver.com...

  • Page 14: Server Side Nodes

    5.4.1 FieldServer Specific Map Descriptor Parameters Column Title Map_Descriptor_Name Data_Array_Name Data_Array_Location Function FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Provide name for node Node ID of physical server node...

  • Page 15: Driver Specific Map Descriptor Parameters

    Length Address Format 5.4.3 Timing Parameters Column Title Scada_Hold_Timeout FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Data type Use one of the Data Types specified in brackets. Length of Map Descriptor Ensure that the length does not exceed the table length in the PLC.

  • Page 16: Map Descriptor Example

    FS-8704-13 GE-SRTP 5.4.4 Map Descriptor Example. In this example the FieldServer can respond to polls the request %R data provided that the request is in the range of address indicated below. Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Address, Length, Data_Type Server-R-Data...

  • Page 17: Driver Notes

    The statistics recorded by the GE-SNPX Serial Driver are slightly different from the way that Fieldserver driver normally record statistics. This difference arises from the fact that this driver is not a simple poll response driver. Bare in mind that a single poll can generate a large number of response fragments.

  • Page 18: Driver Error Messages

    SRTP:#3 Error. MapDesc=<%s> has bad data type. You must edit the CSV file, correct the problem and then reset the FieldServer to correct this problem. Read the manual to get a list of valid data types.

  • Page 19: Scaling

    A panic is produced by this message. There is no corrective action that you can take. If you wish, take a log file using RUIdebug and contact Fieldserver support. SRTP:#10 Err. Session Mbox bad type. Act/Exp=%x/c0 SRTP:#11 Err.
