FS-8704-06 BACnet IP Driver Manual
FieldServer # 2
// Common Information
Bridge
Title , System_Address
Server-1 Pumping Package #2 , 1
// Data Arrays
//
Data_Arrays
Data_Array_Name , Data_Format
DA_AI , UINT16
DA_AO , UINT16
DA_DI , Bit
DA_DO , Bit
Connections
Adapter , Protocol , Connection_Type
N1 , Bacnet_IP , BBMD
Nodes
Node_Name , Node_ID , Protocol
Server-1 , 11276 , Bacnet_IP
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name
HWRemoteCall , DA_DO
HWCommonAlarm , DA_DI
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
, Data_Array_Length
, 200
, 200
, 200
, 200
, IP_Port
, 47808
, Data_Array_Offset , Function , Node_Name
, 0 , Passive , Server-1
, 0 , Passive , Server-1
Page 25 of 57
, Object_Type , Object_Instance , Units
, BO , 1 , No-Units
, Bl , 1 , No-Units
, Relinquish_Default
, 0
, -
