FS-8704-06 BACnet IP Driver Manual
5

CONFIGURING THE FIELDSERVER AS A BACNET IP CLIENT

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See ".csv" sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a BACnet/IP Server.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for BACnet/IP communications, the driver independent FieldServer buffers need to be declared in
the "Data Arrays" section, the destination device addresses need to be declared in the "Client Side Nodes" section,
and the data required from the Servers needs to be mapped in the "Client Side Map Descriptors" section. Details
on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1

Client Side Connection Parameters

Section Title
Connection
Column Title Function
Adapter Adapter Name
Protocol Specify protocol used
Poll_Delay* Time between internal polls
Specify the UDP port that will be used to communicate
IP_Port*
with other BACnet Client devices.
Example
// Client Side Connections
Connections
Adapter , Protocol
N1 , Bacnet_IP
4
Consult the appropriate Instruction manual for details of the ports available on specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
, Poll_Delay
, 0500s
Page 8 of 57
Legal Values
4
N1, N2
BACnet_IP
0-32000s; 0.25s
Any legal IP port value (1 - 65535);
47808
