- Page 1 Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-23 Cleaver Brooks Hawk APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after April 2011 A Sierra Monitor Company Driver Version: 1.01 Document Revision:...
-
Page 2: Table Of Contents
Appendix A.2. Driver Compatibility Matrix ... 11 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Party Equipment ... 3 Table of Contents... -
Page 3: Cb-Link Description
FS-8700-23 Cleaver Brooks Hawk Driver Manual CB-LINK DESCRIPTION The CB-Link driver allows the FieldServer to transfer data to and from devices over RS-485 using CB-Link protocol. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer. -
Page 4: Hardware Connections
TRAPSCAN) Q7700 NETWORK INTERFACE. HAWK FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com AKA: ASCII INTERFACE A B C RS485 9600 N81... -
Page 5: Data Array Parameters
, Data_Array_Format DA_AI_01 , Float FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com , Data_Array_Length , 200 Page 5 of 11 Legal Values... -
Page 6: Configuring The Fieldserver As A Chb-Link Client
FS-8700-23 Cleaver Brooks Hawk Driver Manual CONFIGURING THE FIELDSERVER AS A CHB-LINK CLIENT For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv”... -
Page 7: Client Side Node Descriptors
Tdenh Testcard Trapscan FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Legal Values Up to 32 alphanumeric characters Refer to Section 5.3.1... -
Page 8: Node_Type
Timeout Specify maximum response time FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Legal Values Any of the variable names in the related .bp2 property file. -
Page 9: Map Descriptor Example
, DA_AI_01 Oper_Pressure , DA_AI_01 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 9 of 11 , Data_Array_Offset , Function , Node_Name... -
Page 10: Appendix A. Reference
Each Controller interfacing to the FieldServer requires associated property files (denoted by file extensions .bp1 and .bp2) to be loaded into the FieldServer. The property files listed in the device information table (Appendix A.1) are preloaded onto the FieldServer when delivered. Other property files may be available upon request. -
Page 11: Appendix A.1.2. Configuration Files
SlotServer ProtoNode ProtoCessor FPC-FO2 ProtoCessor FPC-FD2 QuickServer FS-QS-1010 QuickServer FS-QS-1011 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 11 of 11...
