D Mounting the transceiver
The unversal mountng bracket suppled wth your trans-
cever allows overhead mountng.
• Mount the transcever securely wth the 4 suppled screws to a
thck surface whch can support more than 1.5 kg.
Flat washer
Spring washer
When using
self-tapping screws
CONNECTION AND MAINTENANCE
3
