Icom IC-F521 Instruction Manual page 7

[BANK] BANK KEY
Select and determne a bank number.
• Push [BANK] then push [CH UP]/[CH DN] to
select operatng bank number, and then push
[BANK] to determne the bank number.
[SCAN A] SCAN START/STOP KEY
[SCAN B] Push ths key to start scannng; and push agan
to stop.
NOTE: Place the mcrophone on hook to
start scannng.
Take the mcrophone off hook to stop scan-
nng.
Push and hold ths key to ndcate the scan
group, then push to select the desred group.
[TAG] SCAN TAG KEY
Adds or deletes the selected channel to the
scan group.
[LOCK] LOCK KEY
Electroncally locks all programmable keys ex-
cept the followng:
• [ ] (ncl. [CAL A] and [CAL B]), [
CALL
[ ] keys.
EMER
[MONI]
[W/N]
[H/L]
] and
MONI
PANEL DESCRIPTION
MONITOR KEY
Actvates one of (or two of) the followng func-
tons on each channel ndependently:
• Push and hold the key to unmute the channel (audo
s emtted; 'Audble' condton).
• Push the key to toggle the mute and unmute cond-
tons (toggles 'Audble' and 'Inaudble').
• Push the key to mute the channel (sets to 'Inaudble'
only).
• Push the key to unmute the channel (sets to 'Audble'
only).
• Push the key after the communcaton s fnshed to
send a 'reset code'.
NOTE: The unmute condton ('Audble' cond-
ton) may automatcally return to the mute
condton ('Inaudble' condton) after a spec-
fied perod.
WIDE/NARROW KEY
Push [W/N] to toggle bandwdth between wde
or narrow.
OUTPUT POWER SELECTION KEYS
Select the transmt output power temporarly or
permanently dependng on the pre-settng.
• Ask your Dealer or System Operator for the
output power level for each selecton.
1
4
