Full analysis:
latest/esm.smstatus - the output of the smControl status command
for all selected chassis.
latest/esm.smShowDefBcGroup - the output of the
smShowDefBcGroup command for all selected chassis.
latest/esm.smShowDefBcGroup.diff - diff of baseline and latest
smShowDefBcGroup.
latest/esm.smShowSMParms - the output of the smShowSMParms
command for all selected chassis latest/esm. smShowSMParms.diff - diff
of the baseline and the latest smShowSMParms.
The .diff files are only created if differences are detected.
If the -s option is used and failures are detected, files related to the checks that
have failed are also copied to a time stamped directory name under
FF_ANALYSIS_DIR, such as:
FF_ANALYSIS_DIR/2007-11-22-09:53:04
5.6.6.1
Chassis SM items that are checked against the baseline
Based upon smShowSMParms:
SM priority
❥
SM sweep rate
❥
SM retry and timeout
❥
SM fabric timeouts configured (switchLifeTime, HoqLife, VLStall,
❥
PacketLifeTimes for PathRecords)
Multipath mode
❥
❑
Default IPoIB broadcast group settings in SM (PKey, MTU, Rate, SL)
❥
5.6.6.2
Chassis SM items also checked during healthcheck
Based upon smControl status:
SM is in running state
❥
D000006-000 Rev A
Based on smShowDefBcGroup
