Upgrading The Computer
Figure 6 - 5
HDD Removal
6
Figure 6 - 6
HDD Bracket
Screws
6 - 6 Upgrading the Hard Disk Drive
6.
Carefully remove the hard disk assembly in the direction of the arrow
-
7.
Remove screws
19
8.
Reverse the process to install any new hard disk.
18
to separate the hard disk from the bracket.
22
19
20
22
21
.
18
18
