EUROCOM Notebook V12.1.00 User Manual page 127

5. Remove screws &
5
plate .
8
6. Reverse the process to install a new disk (pay careful attention to the orientation of
the hard disk in the case bracket before tightening the screws).
7. Insert the new HDD into the case along with the insulation plate and replace the
crews.
8. Reinsert the HDD assembly back into the case and replace the screws
(Figure 6 - 6 on page 6 -
9. Replace the component bay cover (see page
and separate the case bracket
6
8
5
10).
6 -
and the insulation
7
6
7
1
6).
Upgrading the Hard Disk Drive(s) 6 - 11
Upgrading The Computer
Figure 6 - 7
Secondary
Hard Disk Case
Bracket & Insulation
Plate Removal
&
2
6
