Setup For Audio Recording - EUROCOM Notebook V12.1.00 User Manual

Storage Devices, Audio & Mouse
2
Figure 2 - 6
Realtek Audio
Manager -
Recording Setup
2 - 8 Audio Features

Setup for Audio Recording

To record audio sources on your computer at optimum quality follow the instruc-
tions below:
1. Click Start, and click Control Panel (or point to Settings and click Control Panel)
and make sure you are in Classic View.
2. Click Realtek HD Audio Manager (or right-click the taskbar icon
Sound Manager).
3. Click Microphone Effects (tab) in Microphone (tab), and then click to select
Noise Suppression (button), or adjust the Recording Volume level to around 60,
to obtain the optimum recording quality.
4. Click OK to close the control panel and save the settings.
and select
