EUROCOM Notebook V12.1.00 User Manual page 124

Upgrading The Computer
6
Figure 6 - 4
Primary HDD Cover
Removal
6 - 8 Upgrading the Hard Disk Drive(s)
Removing the Hard Disk from the Primary HDD Bay
1. Turn off the computer, and turn it over and remove the battery (see page
2. Remove screw .
1
3. Slide the HDD cover in the direction of arrow
4. Lift the HDD cover out of the computer
2
until the case markers line up.
2
.
3
1
2
6 - 4).
3
