System Map: Rear View

Figure 1 - 6 - Rear View
1. Carrying Handle
2. Headphone-Out Jack
3. Line-In Jack
4. Microphone-In Jack
5. RJ-45 LAN Jack
6. RJ-11 Phone Jack
7. 2 * USB 2.0 Ports
8. Unpowered - IEEE 1394
Port
9. Printer/Parallel Port
10. Serial Port
11. External Monitor Port
12. Vents
13. Hard Disk Bay Screw
2 3 4 5 6
1 - 12 System Map: Rear View
12
12
7 8 9
12
1
12
12
13
10 11
The IEEE 1394 port only supports SELF
POWERED IEEE 1394 devices.
Handle Warning
We strongly recommend using both
hands to move the computer (one
hand gripping the handle and the
other gripping the base) to avoid
accidentally dropping it.
Port Warning
The computer can only accept one
keyboard at a time. Don't try to in-
stall more than one keyboard at the
same time. Doing so may cause re-
source conflicts and make the sys-
tem unstable.
IEEE 1394
