System Map: Right View

9
1
2
4 3
5
8
6
7
7-in-1 Card Reader Formats
The card reader allows you to use the most popular
digital storage card formats (see page
• MMC (MultiMedia Card)
• SD (Secure Digital)
• MS (Memory Stick)
• MS Pro (Memory Stick Pro)
• MS Duo (requires PC adapter)
• Mini SD (requires PC adapter)
• RS MCC (requires PC adapter)
The PC Card Slot
The computer is equipped with a PCMCIA 3.3V/5V
slot (see page 2 - 13).
Sound Volume Adjustment
How high the sound volume can be set depends on
the setting of the volume control within Windows, and
the volume control knob on the right of the com-
puter. Click the volume icon
the setting (see "Audio Features" on page 2 -
1.
2.
3.
2 - 12):
4.
5.
6.
7.
8.
9.
Note: Only Model B is pictured
(right and rear views), however the
port locations etc. are identical to
Model A.
in the taskbar to check
11).
System Map: Right View 1 - 11
Quick Start Guide
Figure 1 - 5 - Right View
LCD Brightness Control
Knob
Volume Control Knob
7-in-1 Card Reader
PC Card Slot
PC Card Eject Button
2 * USB 2.0 Ports
AC-In Jack
Security Lock Slot
Vent
