Upgrading The Computer
Figure 5 - 5
Rear Case
Removal
5
Figure 5 - 6
RAM Removal
5 - 6 Upgrading the System Memory (RAM)
5. Carefully remove the rear cover
6. The memory sockets will now be visible at point
13
Model A
7. Carefully push the two latches (
release the module.
8. Push the latches to release the second module if necessary.
9. The module will "pop-up" slightly, and you may remove it.
and set it aside.
12
12
13
Model A
and ) toward the sides of the socket to
14 15
14
14
on the mainboard.
13
12
Model B
15
15
