System Map: Front View

1. LCD Panel
2. Speakers
3. LED Indicators
4. Power Button
5. Optical (CD/DVD) Device Bay (Model B
Only - see page
6. Keyboard Holder (Model B Only)
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g.
due to an unexpected power interruption) you
may push the end of a straightened paper clip
into the emergency eject hole. Do not use a
sharpened pencil or similar object that may
break and become lodged in the hole.
Media Warning
Don't try to remove a floppy disk/CD/DVD
while the system is accessing it. This may
cause the system to "crash".
1 - 6 System Map: Front View
1 - 10 for Model A)
Figure 1 - 2 - Front View
Model A
1
2 2
3 4
Model B
1
6 6
3
4
5
