System Map: Rear View

Figure 6 - Rear View
1. Carrying Handle
2. Headphone-Out Jack
3. Line-In Jack
4. Microphone-In Jack
5. RJ-45 LAN Jack
6. RJ-11 Phone Jack
7. Dual USB Ports
8. Unpowered - IEEE 1394 Port
(optional with Mini PCI IEEE
1394 Module)
9. PS/2 Mouse & Keyboard
Ports
10. Printer/Parallel Port
11. Serial Port
12. External Monitor Port
13. Vents
14. Hard Disk Bay Screw
3
2 4
6
5
7
14 - System Map: Rear View
13
13
9
8 10
13
1
13
14
13
12
11
The IEEE 1394 port only supports SELF
POWERED IEEE 1394 devices.
Handle Warning
We strongly recommend using
both hands to move the computer
(one hand gripping the handle and
the other gripping the base) to
avoid accidentally dropping it.
Port Warning
The computer can only accept one
keyboard at a time. Don't try to in-
stall a USB and a PS/2 keyboard at
the same time. Doing so may
cause resource conflicts and make
the system unstable.
IEEE 1394
