Upgrading the System Memory (RAM)

The computer can accommodate up to 2GB of memory in two DIMM sockets. See
"Memory" on page B - 3
1. Unplug the power cord and disconnect all peripheral cables (including the phone
line) from the computer.
2. Turn off the computer.
3. Place the computer with its LCD display facing down on a clean, dry, level surface.
4. Remove screws -
1
1
2
11
9
10
for more details.
from the rear of the computer.
11
3
4
5
7
8
6
Upgrading The Computer
Card Reader/PC
Card Slots
Make sure you remove
any cards or covers in
the 7-in-1 Card Reader
and PC Card slot be-
fore removing the rear
case cover.
Upgrading the System Memory (RAM) 5 - 5
Warranty Warning
Note that the procedure to
upgrade or replace the
memory involves exten-
sive disassembly of the
system. We strongly rec-
ommend that you do not
upgrade/replace the sys-
tem memory yourself.
Please contact your ser-
vice representative for as-
sistance.
Supported RAM
Module Types
Use ONLY the RAM mod-
ule types indicated in
"Memory" on page B - 3.
Figure 5 - 4
Rear Case Screws
5
