System Map: Rear View

13
1
13
13
2
3 4
5
6
13
The computer can only accept
one keyboard/mouse at a time.
Don't try to install a USB and a
PS/2 keyboard/mouse at the
same time. Doing so may cause
resource conflicts and make the
system unstable.
The optional IEEE 1394 port only
supports SELF POWERED IEEE
13
1394 devices.
9
7
8
Port Warning
IEEE 1394
11
10
12
Concise User's Guide
Figure 6
Rear View (All Models)
1.
Carrying Handle
2.
Headphone-Out Jack
3.
Line-In Jack
4.
Microphone-In Jack
5.
RJ-45 LAN Jack
6.
RJ-11 Phone Jack
7.
Dual USB Ports
8.
IEEE 1394 Port - unpowered
(optional with Mini PCI
IEEE 1394 Module)
9.
PS/2 Mouse & Keyboard
Ports
10. Printer/Parallel Port
11. Serial Port
12. External Monitor (VGA) Port
13. Vents
System Map: Rear View - 15
