Appendix B: Schematic Diagrams
This appendix has circuit diagrams of the M62N notebook's PCB's. The following table indicates where to find the ap-
propriate schematic diagram.
Diagram - Page
System Block Diagram - Page B - 2
Yonah 1/2 - Page B - 3
Yonah 2/2 - Page B - 4
945GMS 1/5 HOST - Page B - 5
945GMS 2/5 - Page B - 6
945GMS 3/5 DDR - Page B - 7
945GMS 4/5 - Page B - 8
945GMS 5/5 - Page B - 9
DDRII SO-DIMM - Page B - 10
Memory Down-1 - Page B - 11
Memory Down-2 - Page B - 12
DDR Series Termination - Page B - 13
CRT, Panel, Inverter - Page B - 14
ICH7-M 1/4, BT - Page B - 15
ICH7-M 2/4, PCI, USB, SPI - Page B - 16
ICH7-M 3/4, FWH - Page B - 17
ICH7-M 4/4 - Page B - 18
Diagram - Page
HDD/ODD, USB2.0 * 1 - Page B - 19
Clock Generator, Fan, TP - Page B - 20
Marvell 88E8038 - Page B - 21
PCI7412, 1394 - Page B - 22
PCM Socket, 3 In 1 Socket - Page B - 23
H8/21111 - Page B - 24
ALC260, PC-BEEP - Page B - 25
AMP, TPM, MINI PCIE - Page B - 26
Audio B'd, FP, MDC, Vista - Page B - 27
LED, HALL IC, SUS PWR - Page B - 28
+VDD3, +VDD5, +3V, +5V - Page B - 29
+VCORE - Page B - 30
Memory Power +1.8V, +0.9VS - Page B - 31
VCCP +1.5VS, +1.05VS - Page B - 32
AC-In, Charger - Page B - 33
Fingerprint B'd - Page B - 34
Lid SW B'd - Page B - 35

Schematic Diagrams

Table B - 1
Schematic
Diagrams
Version Note
The schematic dia-
grams in this chapter
are based upon ver-
sion 6-7P-M62E3-001.
If your mainboard (or
other boards) are a lat-
er version, please
check with the Service
Center for updated di-
agrams (if required).
