Disassembly
4. Remove screw
Figure 12
5. Lift the Bluetooth module
Bluetooth Module
Removal
c.
c. Remove the screw.
d. Disconnect the cable.
e. Remove the Bluetooth
module.
Note: The Bluetooth
cable is colored gray.
6. Bluetooth Module
• 1 Screw
2 - 16 Removing the Bluetooth Module
then disconnect the cable
.
4
5
up off the mainboard.
6
4
e.
d.
5
6
