Upgrading The Computer
6
Figure 6 - 5
Primary HDD
Assembly Removal
6 - 10 Upgrading the Hard Disk Drive(s)
Removing the Hard Disk from the Primary HDD Bay
Note that only Model B is pictured, however the procedure for removing the primary
hard disk from Model A is the same.
1. Turn off the computer, and turn it over and remove the battery and component bay
cover (see pages 6 - 4
2. Lift up the protective rubber on the insulation plate at points
3. Slide the HDD assembly in the direction of arrow
4. Lift the HDD assembly out of the computer
1
2
& 6 - 6).
.
4
3
& .
1 2
.
3
4
