Removing the System Memory

1. Turn the computer OFF, remove the battery
2. Remove screw from the RAM cover
1
3. Locate the memory sockets
3
toward the sides of the computer as indicated.
4. The module (Figure 2 - 2c) will pop-up, and you can remove it.
7
5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.
a.
2
c.
7
(page 2 - 6).
(Figure 2 - 2a), and lift the cover
& (Figure 2 - 2b), and gently pull the latches
4
b.
1
up off the computer.
2
& on the memory socket
5 6
3
5 6
4
5 6
Removing the System Memory 2 - 7
Disassembly
Figure 2 - 2
Memory Removal
Sequence
a. Remove the screw,
then remove the
RAM cover.
b. Pull the latch(es) on
the memory sockets
to release the mod-
ule(s).
c. When the module
pops up, lift it out.
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's perform-
ance.
2. RAM cover
7. Memory module(s)
• 1 Screw
