Disassembly

Removing the Keyboard

Figure 2 - 3
Keyboard
1. Turn the computer OFF and remove the battery
Removal
2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you
Sequence
may need to use a small screwdriver to do this).
3. Carefully lift the keyboard
a. Press the four latch-
4. Disconnect the keyboard ribbon cable from the locking collar socket
es to release the
keyboard.
a.
b. Lift the keyboard out
and disconnect the
cable from the lock-
ing collar.
Re-Inserting the Key-
board
When re-inserting the
keyboard firstly align
the four keyboard tabs
Figure 2 - 3
( c) at
c.
the bottom of the key-
board with the slots in
the case.
7. Keyboard
2 - 8 Removing the Keyboard
up and out, being careful not to bend the keyboard ribbon cable
7
1 2 3
7
7
Keyboard Tabs
(page 2 - 6).
(Figure 2 -
6
b.
4
(Figure 2 - 3b).
5
3b).
6
5
