EUROCOM M22ES Service Manual page 35

4. Fully raise latch in the direction indicated in
1
5. Carefully (it may be hot) lift the CPU
6. When re-inserting the CPU pay careful attention to the pin alignment, it will fit only one way (don't force it!).
a.
1
Figure 2 - 6a to unlock the CPU.
up out of the socket (Figure 2 -
2
b.
6b).
2
Disassembly
Figure 2 - 6
Processor
Removal
Sequence
(Cont.)
a. Raise the latch to
unlock the CPU.
b. Lift the CPU out of
the socket.
2. CPU
Removing the CPU 2 - 11
