Disassembly

Removing the Mainboard

Figure 2 - 13
Mainboard
1. Remove the battery
Removal
(page 2 -
Sequence
2. Remove screws
3. Lift the mainboard
a. Remove the screws
and hex nut.
b. Lift the mainboard
a.
out of the bottom
case.
5. Mainboard
6. Bottom case
• 3 Screws
• 1 Hex nut
2 - 16
(page 2 - 6), keyboard
12), CD device (page 2 - 12), bottom case
- and hex nut .
1 3 4
out of the bottom case
5
4
1
2
(page 2 - 8), HDD assembly (page 2 -
(page 2 - 13) and FDD assembly
(Figure 2 - 13).
6
b.
3
9), CPU (page 2 - 10), modem
(page 2 - 15).
5
6
