Upgrading The Computer
Figure 6 - 6
Lower Slot Hard
Disk Assembly
6
Removal
6 - 10 Upgrading the Hard Disk Drive(s)
Removing the Hard Disk from the Lower HDD Bay Slot
1. Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat-
tery and any HDD in the upper slot.
2. Slide the HDD assembly in the direction of arrow
3. Raise the HDD assembly up at an angle
4. Remove the HDD assembly from the bay
1
2
.
1
as illustrated.
2
.
3
3
