This property is the same as Ethernet@Wirespeed, and is only available when the blade server is attached to a pass-through module.
Chassis PHY Flow Control
This property is the same as Flow
Chassis PHY Speed & Duplex
This property is the same as Speed & Duplex
Chassis SW Flow Control
This property is the same as Flow
Chassis SW Speed & Duplex
This property is the same as Speed & Duplex

Configuring System Settings

System Management on the Configurations tab allow you to view and change the values of the available properties for the system. The potentially
available properties and their respective settings are described below.
Chimney Offload State
Enables TCP Offload Engine (TOE) for the entire system. On Windows Server 2003 and Windows Server 2008 operating systems, the options are Enable
(default) and Disable. For Windows Server 2008 R2, the options are Enable, Disable, and Auto (default). If Chimney Offload State is configured for Auto,
then a 10 Gbps network adapter will have TOE enabled, but not for a 1 Gbps network adapter.
To enable TOE for individual network adapters, configure Chimney Offload State to Enable and also enable TCP Connection Offload (IPv4) or TCP
Connection Offload (IPv6) from the Advanced area of the Configuration tab.

Viewing Statistics

The information provided on the Statistics tab allows you to view traffic statistics for both Broadcom network adapters and network adapters made by
others. Statistical information and coverage are more comprehensive for Broadcom adapters.
To view Statistics information for any installed network adapter, click the name of the adapter listed in the Device Management pane, then click the
Statistics tab.
If the Statistics tab is not visible, then from the View menu, select Navigate, then Device Management, and then Statistics.
If any of the sections described below is not visible, then from the Context View tab on the right side of the window, select Statistics and then
select the name of the missing section.
Click Refresh to get the most recent values for each statistic. Click Reset to change all values to zero for the current BACS3 session.
NOTES:
Team statistics are not compiled for a Broadcom network adapter if it is disabled.
Some statistics may not be available for all Broadcom network adapters.
Control, and is only available when the blade server is attached to a pass-through module.
(excludes 1 Gb Full Auto), and is only available when the blade server is attached to a pass-through module.
Control, and is only available when the blade server is attached to a switch module.
(SerDes), and is only available when the blade server is attached to a switch module.
