Switch Status Indicators

System activity and status can be determined through the activity of the
LEDs on the switch.
The LEDs may flash yellow during diagnostic tests, and green,
Note
yellow, or orange during POST. This is normal, and does not indicate a
problem unless the LEDs do not display a healthy pattern after POST or the
other diagnostic tests are complete.
The orange light may be referred to as "amber" in other documentation.
The switch includes the following LEDs:
• Eight port status LEDs on the SFP media side (above and to the left of
each port) to indicate the status of each port.
• Eight port speed LEDs on the SFP media side (above and to the right of
each port) to indicate the current link speed of each port.
• One switch status LED on the SFP media side and one on the fan side,
to indicate whether the switch is on and has successfully booted, and
whether any of the ports are faulty.
