6
(6) Spacer (Compaq/Rittal rack only)
(4) M5 flat washer (Compaq/Rittal rack only)
For proper airflow, the SFP media side of the FC Entry Switch
CAUTION
8B or FC Switch 8B faces the rear of the rack. This mounting allows air to
enter the front of the rack through the plenum and to exhaust at the rear of
the rack, similar to other rack-mounted equipment. This prevents switch
overheating that may cause it to fail.
To install the switch in an HP rack:
1. Check contents of the shipping carton to verify all the required parts and
hardware are available.
2. Choose a mounting location in the rack for the switch.
3. Attach the rear rail-tray brackets to the rear rack uprights by installing
each of the two mounting brackets with one M5 Torx head screw with
captive lock washer as shown in Figure 2.
