38
Color of LED Status of Hardware
Flickering green Port is online, with traffic
flowing through port.
Steady orange Port is receiving light or signal
carrier, but is not yet online.
Slow-flashing The port is disabled
orange (on 1 (result of diagnostics or
second; off 1 portDisable command).
second)
Fast-flashing The port is faulty.
orange (on 1/4
second; off 1/4
second)
Alternating green
and yellow
The following table describes the port speed LEDs located above each port
on the right.
Color of LED Status of Hardware
No light The port is
transmitting/receiving at
1 Gbps.
Steady green The port is
transmitting/receiving at
2 Gbps.
No light The port is
transmitting/receiving at
10 Mbps.
Steady green The port is
transmitting/receiving at
100 Mbps.
Port is bypassed.
Recommended Action
No action required.
No action required.
Reset the port from a
management station.
Reset the switch from
a management
station.
Reset the port from a
management station.
Recommended Action
No action required.
No action required.
No action required.
No action required.
