4. Remove the PC Card assembly (2).
Reverse this procedure to install the PC Card assembly.

USB/audio board

Description
USB/audio board (includes USB cable and audio cable)
Before removing the USB/audio board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Hard drive (see
b. Optical drive (see
c. Keyboard (see
d. Fan (see
e. Heat sink (see
f. Switch cover (see
g. TouchPad (see
h. Display assembly (see
Battery on page
Hard drive on page
Optical drive on page
Keyboard on page
Fan on page 61)
Heat sink on page
Switch cover on page
TouchPad on page
Display assembly on page
45).
49)
53)
57)
62)
71)
67)
75)
Component replacement procedures
Spare part number
455426-001
