e.
Heat sink (see
f.
Switch cover (see
g.
TouchPad (see
h.
Display assembly (see
i.
Top cover (see
j.
Speaker assembly (see
k.
Modem module (see
When replacing the system board, be sure that the following components are removed from the defective
system board and installed on the replacement system board:
SIM (see
Memory module (see
WLAN module (see
WWAN module (see
Processor (see
Graphics card (see
PC Card assembly (see
Remove the system board:
1.
Disconnect the following cables from the system board:
(1) RJ-11 connector cable
(2) USB board cable
(3) Audio board cable
(4) Bluetooth module cable
2.
Position the base enclosure with the rear panel toward you.
86
Chapter 4 Removal and replacement procedures
Heat sink on page
Switch cover on page
TouchPad on page
Display assembly on page
Top cover on page
Speaker assembly on page
Modem module on page
SIM on page
46)
Memory module on page
WLAN module on page
WWAN module on page
Processor on page
Graphics card on page
PC Card assembly on page
62)
71)
67)
75)
80)
82)
84)
55)
69)
59)
64)
65)
89)
