d. Fan (see
e. Heat sink (see
f. Switch cover (see
g. TouchPad (see
h. Display assembly (see
i. Top cover (see
j. Speaker assembly (see
k. Modem module (see
l. System board (see
Remove the PC Card assembly:
1. Turn the system board upside down, with the front toward you.
2. Remove the two Phillips PM2.0×3.0 screws that secure the PC Card assembly to the system board.
3. Detach the slots on the PC Card assembly from the tabs on the PC Card connector (1).
90 Chapter 4 Removal and replacement procedures
Fan on page 61)
Heat sink on page
Switch cover on page
TouchPad on page
Display assembly on page
Top cover on page
Speaker assembly on page
Modem module on page
System board and system board frame on page
62)
71)
67)
75)
80)
82)
84)
85)
