9.
Remove the top cover (3).
10.
If it is necessary to replace the microphone, turn the top cover upside down with the front toward
you.
11.
Remove the microphone cable from the clips (1) built into the top cover.
12.
Remove the microphone receiver (2) from the clip (3) built into the top cover.
Reverse this procedure to install the top cover.
Speaker assembly
Description
Speaker assembly
82
Chapter 4 Removal and replacement procedures
Spare part number
452225-001
