HP Compaq 8510p - Compaq Business Notebook Maintenance And Service Manual page 41

Spare part Description
number
452196-001 Broadcom Bluetooth module for use in all countries and regions except Japan and Asia Pacific countries and
regions
NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth module
cable is included in the Cable Kit, spare part number 452198-001. See
Kit spare part number information.
452197-001 Base enclosure (includes rubber feet)
452198-001 Cable Kit (see
452199-001 Fan
452200-001 100-GB, 7200-rpm hard drive (includes hard drive bracket)
452207-001 15.4-inch WXGA display assembly for use with computer models equipped only with WLAN capability (includes
3 WLAN antenna transceivers and cables)
452208-001 15.4-inch WSXGA+ display assembly for use with computer models equipped only with WLAN capability
(includes 3 WLAN antenna transceivers)
452209-001 15.4-inch WUXGA display assembly for use with computer models equipped only with WLAN capability
(includes 3 WLAN antenna transceivers and cables)
452210-001 15.4-inch WXGA display assembly for use with computer models equipped with WLAN and WWAN capability
(includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
452211-001 15.4-inch WSXGA+ display assembly for use with computer models equipped with WLAN and WWAN
capability (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
452212-001 15.4-inch WUGA display assembly for use with computer models equipped with WLAN and WWAN capability
(includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
452213-001 Display hinges
452214-001 Display inverter
452215-001 Display bezel for use with computer models equipped with only WLAN capability
452216-001 Display enclosure for use with computer models equipped only with WLAN capability (includes 3 WLAN
antenna transceivers)
452217-001 Display enclosure for use with computer models equipped with WLAN and WWAN capability (includes 3 WLAN
antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
452218-001 System board for use with computer models equipped only with WLAN capability
452219-001 System board for use with computer models equipped with WLAN and WWAN capability
452220-001 Blu-Ray DVD-RW Drive
452221-001 Plastics Kit (see
452222-001 Screw Kit
452223-001 Top cover for use with HP Compaq 8510p computer models (does not include fingerprint reader board)
452224-001 Top cover for use with HP Compaq 8510w computer models (includes fingerprint reader board and cable)
452225-001 Speaker assembly
452226-001 Switch cover (includes LED board and cable)
452227-001 Heat sink (includes a heat sink clip and replacement thermal material)
452228-001 Keyboard without pointing stick for use in the United States
Cable Kit on page 27 for more Cable Kit spare part information)
Plastics Kit on page 26 for more Plastics Kit spare part information)
Cable Kit on page 27 for more Cable
Sequential part number listing 33
