Left-side components

Item Component
(1) Security cable slot
(2 RJ-45 (network) jack
(3) 1394 port (select models only)
(4) Vent
(5) HDMI port
(6) USB ports (2)
(7) Media Card Reader
(8) PC Card slot (select models only)
Function
Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
Connects a network cable.
NOTE: The RJ-45 (network) jack provides Gigabit
Ethernet functionality.
Connects an optional IEEE 1394 or 1394a device, such as
a camcorder.
Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
Connects an optional video or audio device, such as a high-
definition television, or any compatible digital or audio
component.
Connect optional USB devices.
Supports the following optional digital card formats:
MultiMedia Card (MMC) and Secure Digital (SD) Memory
Card.
Supports optional Type I or Type II 32-bit (CardBus) or 16-
bit PC Cards.
Left-side components 13
