The Timer Statistics chart automatically updates within the time interval you
have set. Set the time interval to update information (from 1 second to 23 hours,
59 minutes, 59 seconds) by using the clock symbol at the bottom of the window.
See

Station Timer Statistics Window Fields

The Timer Statistics window fields display the different network events measured
by the Timer Statistics chart. The following Timer Statistics window fields appear
for the network:
Frames
Displays the elapsed, average, and peak levels of good frames generated by the
station attached to the port.
Errors
Displays the elapsed, average, and peak levels of errors received by the station
port.
KBytes
Displays the elapsed, average, and peak levels of kilobytes processed by the
station port.

Port Performance Graphs

Port Performance Graphs
color-coded strip charts allow you to visually track the performance of the
selected station. Each strip chart graph shows you the amount of traffic going
through the station port, as well as the number of errors experienced at the
particular port.
Directly above the graph, three fields identify the currently selected port by its
board and port index and its MAC address.
Port Level Statistics
Setting the Statistics Poll Interval, page 3-3, for details.
(Figure 3-13) provide real-time statistics reporting. The
Token Ring Statistics
3-23
