If you selected AutoMode, the module will now be configured to operate
according to its default hardware settings. Note that if a set is made to the module
using NetSight Element Manager, the module will automatically return to
management mode.

Enabling and Disabling Ports

Enabling and Disabling Station Ports

From the Module and Port menus on the MicroMMAC-T Chassis View window,
you can enable and disable all station ports on a selected module, as well as
individual station ports, respectively.
To enable or disable all station ports on a selected module:
1. Click on the Module Index for the desired module. The Module pull-down
2. Click on Enable Station Ports to enable the ports, or Disable Station Ports
The module's station ports will now be enabled or disabled as desired.
To enable or disable an individual station port:
1. Click on the Port Index for the desired port. The Port menu will appear.
2. Click on Enable to enable the port, or Disable to disable the port. The port will

Enabling and Disabling Ring Ports

From the Module and Ring Port menus on the MicroMMAC-T Chassis View
window, you can enable and disable all ring-in/out ports on a selected module, as
well as individual ring-in/out ports, respectively.
To enable or disable the Ring-in/Ring-out Ports on a selected module:
1. Click on the Module Index for the desired module. The Module pull-down
2. Click on Enable Ring Ports to enable the ports, or Disable Ring Ports to
The module's Ring-in/Ring-out ports will now be enabled or disabled as desired.
Managing the Hub
menu will appear.
to disable the ports.
now be enabled or disabled as desired.
menu will appear.
disable the ports.
The MicroMMAC-T Chassis View
2-31
