Traffic (Blue)
Frames
Percent Load
Nothing

Configuring the Port Performance Graph

1. Click on the Total Errors button (with the red square marker to its left). The
2. Click on the desired Total Errors mode (Total Errors or Nothing). The mode
3. Click on the Traffic button (with the blue square marker to its left). The Traffic
4. Click on the desired Traffic mode (Frames, Percent Load, or Nothing). The
The Performance Graph will now monitor the station port using the user-defined
mode. (Click on Cancel to stop monitoring and exit the screen.)
Port Level Statistics
The total number of good frames transmitted and
received by the station port.
Reflects the network load generated by the station port
compared to the theoretical maximum load (4 or 16
Mbits/sec.) of a Token Ring Network.
The Traffic scale is not currently measuring the traffic or
load processed by the station port.
Total Errors pull-down menu will appear.
you have chosen will appear in the button. The Performance Graph will
refresh and begin to measure using the new mode.
pull-down menu will appear.
mode you have chosen will appear in the button. The Performance Graph will
refresh and begin to measure using the new mode.
Token Ring Statistics
3-25
