IRM2 User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Enterasys IRM2

Summary of Contents for Enterasys IRM2

  • Page 1 IRM2 User's Guide...
  • Page 3 100% reliable, we strongly caution you to write protect and then verify that the Licensed Software, prior to installing it, is virus-free with an anti-virus system in which you have confidence. Enterasys Networks makes no representations or warranties to the effect that the Licensed Software is virus-free. Copyright 2000 by Enterasys Networks.
  • Page 4 AppleTalk, Apple, Macintosh, and TokenTalk are registered trademarks; and Apple Remote Access and EtherTalk are trademarks of Apple Computer, Inc. SmartBoost is a trademark of American Power Conversion ST is a registered trademark and C++ is a trademark of AT&T Banyan and VINES are registered trademarks of Banyan Systems, Inc.
  • Page 5 (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013. Enterasys Networks, 35 Industrial Way, Rochester, New Hampshire 03867-0505. (a) This computer software is submitted with restricted rights. It may not be used, reproduced, or disclosed by the Government except as provided in paragraph (b) of this Notice or as otherwise expressly stated in the contract.

  • Page 7: Table Of Contents

    Using This Manual... 1-1 Related Manuals... 1-2 Software Conventions ... 1-3 Using the Mouse ... 1-3 Common IRM2 Window Fields ... 1-4 Using Window Buttons... 1-5 Getting Help ... 1 -6 Using On-line Help... 1-6 Getting Help from the Enterasys Global Call Center ... 1-7...
  • Page 8 Contents Chapter 3 Statistics Statistics ..3-1 Accessing the Statistics Windows... 3-2 Statistics Defined... 3-3 Using the Total and Delta Radio Buttons ... 3-4 Timer Statistics... 3-5 Accessing the Timer Statistics Windows ... 3-5 Setting the Timer Statistics Interval... 3-7 Summary Statistics...
  • Page 9 Chapter 8 Redundancy (Continued) Reconfiguring a Circuit ... 7-9 Changing Port Status... 7-10 Resetting a Circuit...7-11 Index Contents...
  • Page 10 Contents viii...

  • Page 11: Chapter 1 Introduction

    Introduction How to use this guide; related guides; software conventions; getting help; IRM2 firmware versions Welcome to the Enterasys Systems NetSight Element Manager for the IRM2 User’s Guide. We have designed this guide to serve as a simple reference for using NetSight Element Manager for the IRM2.

  • Page 12: Related Manuals

    Related Manuals The IRM2 User’s Guide is only part of a complete document set designed to provide comprehensive information about the features available to you through NetSight Element Manager. Other guides which include important information related to managing the IRM2 include: Enterasys’...

  • Page 13: Software Conventions

    Software Conventions NetSight Element Manager’s user interface contains a number of elements which are common to most windows and which operate the same regardless of which window they appear in. A brief description of some of the most common elements appears below; note that the information provided here is not repeated in the descriptions of specific windows and/or functions.

  • Page 14: Common Irm2 Window Fields

    It is often used for drag-and-drop operations to copy information from one window of the screen into another, and to highlight editable text. Common IRM2 Window Fields Similar descriptive information is displayed in boxes at the top of most device-specific windows in NetSight Element Manager, as illustrated in Figure 1-2, below.

  • Page 15: Using Window Buttons

    Indicates the number of users processing information through the IRM2 repeater, board, or port, as determined by MAC addresses. Uptime Displays the amount of time, in a days hh:mm:ss format, that the IRM2 has been running since the last start-up. Using Window Buttons exit a window and terminate any unsaved changes you have made.

  • Page 16: Getting Help

    NetSight Element Manager. Using On-line Help You can use the IRM2 window the device. When you click on a Help button, a window will appear which contains context-sensitive on-screen documentation that will assist you in the use of the windows and their associated command and menu options.

  • Page 17: Getting Help From The Enterasys Global Call Center

    NOTE have an earlier version of firmware and experience problems, contact the Global Technical Assistance Center. Getting Help (603) 332-9400 24 hours a day, 365 days a year Enterasys Networks Technical Support Rochester, NH 03866-5005 support@ctron.com ftp.ctron.com (134.141.197.25) anonymous your email address...
  • Page 18 Introduction Getting Help...

  • Page 19: Chapter 2 The Irm2 Chassis View

    To access the IRM2 Chassis View window, use one of the following options: 1. In any map, list, or tree view, double-click on the IRM2 you wish to manage; 1. In any map, list, or tree view, click the left mouse button once to select the IRM2 you wish to manage.

  • Page 20: Viewing Chassis Information

    Viewing Chassis Information The IRM2 Chassis View window the IRM2 and the hub in which it is installed, including a color-coded port display which immediately informs you of the current configuration and status of all the boards and ports installed in the MMAC chassis.

  • Page 21: Front Panel Information

    Blue indicates an unknown contact status — polling has not yet been established with the IRM2. • Red indicates the IRM2 is not responding to device polls (device is off line, or device polling has failed across the network for some other reason). UpTime The amount of time, in a days hh:mm:ss format, that the IRM2 has been running since the last start-up.

  • Page 22: Menu Structure

    The revision of device firmware stored in the IRM2’s FLASH PROMs. Time The current time, in a 24-hour hh:mm:ss format, set in the IRM2’s internal clock. Date The current date, in an mm/dd/yyyy format, set in the IRM2’s internal clock.
  • Page 23 Device Type..., which displays a window containing a description of the device being modeled (i.e., IRM2). • Edit Device Time... and Edit Device Date..., which allow you to set the IRM2’s internal clock. • System Group..., which allows you to manage the IRM2 via SNMP MIB II.
  • Page 24 • Redundancy brings up a window that allows you to configure a redundancy scheme for the IRM2 and its associated modules. See Chapter 7, Redundancy, for further information. The Port Status Menu The Port Status menu allows you to select the status information that will be displayed in the port text boxes in the logical Chassis View window: •...
  • Page 25 Reset Counters, which lets you refresh the IRM2’s statistical counters to zero. This option is discussed later in this chapter. • Restart..., which you can use to perform a warm boot of the IRM2. This option is discussed later in this chapter. The Utilities Menu The Utilities menu provides access to any utilities provided by NetSight Element Manager for use with the IRM2 module.

  • Page 26: Mim Port Status Displays

    MIM Port Status Displays When you open the Chassis View window, each port on the IRM2 and the associated MIMs installed in the hub will display its Admin/Link status (defined below); to change this status display, select one of the options on the Port Status menu, as described in the following sections.
  • Page 27 SEG (segmented) if the port has been enabled by management and has a valid connection, but has been segmented by the repeater because 33 consecutive collisions have occurred on the attached segment, or the collision detector was on for more than 2.4 µs. Viewing Chassis Information The IRM2 Chassis View...
  • Page 28 The IRM2 Chassis View Because BNC thin coax and AUI ports do not support the link feature, the displayed Admin/Link, Admin, and Link status conditions will not always follow the pattern NOTE described above. Under Admin/Link status mode, BNC ports will display as ON if there is a valid connection and the port has been enabled;...

  • Page 29: Port Status Color Codes

    1. In the Chassis View window, click on View in the menu bar to access the View menu. 2. Drag down to Physical, and release. The Chassis Physical View, will appear. 3. To switch back to the Logical view, select Logical from the menu, and release. Viewing Chassis Information The IRM2 Chassis View...

  • Page 30: The Chassis Manager Window

    The IRM2 Chassis View The Chassis Manager Window Like most networking devices, Enterasys’ and Cabletron’s devices draw their functionality from a collection of proprietary MIBs and IETF RFCs. The Chassis Manager window, the MIB components — and, therefore, the functionality — supported by the currently monitored device.

  • Page 31: Viewing Hardware Types

    Figure 2-5. Sample Device Type Window Module Type From the Board menus on the IRM2 Chassis View window, you can view a description of the Module types in your IRM2-controlled MMAC. To view a Module Type: 1.

  • Page 32: Managing The Hub

    Chassis View also provides you with the tools you need to configure your hub and keep it operating properly. Hub management functions include setting device date and time, configuring the IRM2 front panel repeater port, setting board names, and enabling and disabling ports.

  • Page 33: Resetting Device Counters

    1. Select Repeater from the Chassis View menu; drag down to Reset Counters and release. Restarting the Device You can use the Restart Device option to perform a warm boot of the IRM2. This will reset all counter information to zero and refresh system uptime. Managing the Hub...

  • Page 34: Configuring The Front Panel Repeater Port Association

    CAUTION local management. To change the port association: 1. Click on Port 1 or Port 2 on Board 1 (the IRM2 module). The Port pull-down menu will appear. 2. Click on Port Association... The Port Association window, appear.

  • Page 35: Setting A Board Name

    3. Click on become the active repeater interface and the other will be administratively disabled. The Chassis View display for the IRM2 module will update to reflect the change. Setting a Board Name From the Board menus on the Chassis View window, you can change the names of the manageable boards installed in your MMAC.

  • Page 36: Enabling And Disabling Ports

    The IRM2 Chassis View Enabling and Disabling Ports From the Port menus on the IRM2 Chassis View window, you can enable and disable any individual ports. To enable or disable a port: 1. Click on the desired Port button. The Port menu will appear.

  • Page 37: Interface Performance Statistics/Bar Graphs

    2. Once you have selected the base unit, click on the down arrow in the left-most field to specify the statistic you’d like to display. Note that the options available from this menu will vary depending on the base unit you have selected. Managing the Hub The IRM2 Chassis View 2-19...
  • Page 38 The IRM2 Chassis View After you select a new display mode, the statistics (and graphs, where applicable) will refresh to reflect the current choice, as described below. Raw Counts The total count of network traffic received or transmitted on the indicated interface since device counters were last reset.

  • Page 39: Viewing Interface Detail

    Managing the Hub The number of bytes transmitted by this interface, expressed as a percentage of the theoretical maximum load. (Figure 2-12) provides detailed MIB-II interface Figure 2-12. Detail Interface Statistics The IRM2 Chassis View Figure 2-12, will appear. 2-21...
  • Page 40 The IRM2 Chassis View You can also access this information via the I/F Statistics option available on the individual port menus; see Chapter 3 Statistics, for more information. Three informational fields appear in the upper portion of the window: Description Displays the interface description for the currently selected interface: Ethernet.
  • Page 41 Interface Group window, which can be accessed via the System Group window (select System Group... from the Device menu). Refer to your Generic SNMP User’s Guide for further information on the System Group and Interface Group windows. Managing the Hub The IRM2 Chassis View 2-23...

  • Page 42: Testing And Disabling The Current Interface

    The IRM2 Chassis View Testing and Disabling the Current Interface With the Test button you can test the current interface (e.g., by performing a loopback or some other transmission test). With the Test and Disable buttons, you can test or disable the current interface.

  • Page 43: Chapter 3 Statistics

    Total and Delta radio buttons; setting the Timer Statistics time interval; configuring the performance graphs The statistical information collected and stored by your IRM2 provides you with detailed information about how much traffic your network (or a segment thereof)

  • Page 44: Accessing The Statistics Windows

    Statistics The Active Users and Broadcasts selections are not available for early generation IRM2s equipped with pre-version 2.00 release firmware. NOTE • Transmit Collisions • Receive Collisions • Out-of-Window (OOW) Collisions • Giant Packets • Alignment Errors • CRC Errors •...

  • Page 45: Statistics Defined

    Active Users (Available with Release Version 2.00 Firmware and Above) Displays the number of users (identified by MAC [Ethernet] address) communicating via a port on the IRM2-managed hub. For an individual port, if Active Users is greater than one, it indicates that a port is supporting a trunk connection and will not respond to port locking.

  • Page 46: Using The Total And Delta Radio Buttons

    Displays the number of receive collisions detected by the device, board, or port. Receive collisions are those detected by the IRM2 while it is receiving a transmission. Displays the number of collisions out of the standard collision window (51.2 µs) experienced...

  • Page 47: Timer Statistics

    Timer Statistics You can use the Timer Statistics windows to gather statistical information concerning your IRM2 and its boards and/or ports over a user-set time period. Statistics are displayed both numerically and graphically, using color-coded, dynamic bar charts. These bar charts display the elapsed, average, and peak values for packets, errors, and bytes at the device, board, or port level.
  • Page 48 Statistics 1. Click on Repeater on the Chassis View menu bar to display the repeater menu. 2. Drag down to Timer Statistics... and release. The Repeater Timer Statistics window, To open the board-level Timer Statistics window: 1. Click on the appropriate Board number to display the board menu. 2.

  • Page 49: Setting The Timer Statistics Interval

    You can configure the Summary Statistics windows to view the percentage of the following network activity generated by devices attached to each board in your IRM2, and each port on a board: • Percent Load –– load generated, as a percentage of theoretical maximum load...

  • Page 50: Accessing The Summary Statistics Windows

    Statistics • Percent Errors –– errors detected, as a percentage of total packets • Percent Collisions –– collisions detected, as a percentage of total packets The dynamic bar graphs allow you to immediately observe the amount of activity experienced by each board or port; the scale displayed at the top right of the window indicates the percentage of activity represented by the bar.

  • Page 51: Configuring Summary Statistics

    2. Drag down to Summary Statistics... and release. The Board Summary Statistics window, Figure 3-5. Board-level Summary Statistics Window The board-level Summary Statistics window also has three fields: • The index number assigned to each port. • The current status of the port: ON, OFF, SEG, or NLK. These status conditions and their associated colors are described in detail in Chapter 2 of this manual.

  • Page 52: Performance Graph

    With the Repeater Performance Graphs, you can use real-time statistics reporting to see at a glance the amount of traffic going through your IRM2 at the repeater, board, or port level. The graph has an X axis that indicates the 60 second interval...
  • Page 53 To open the board-level Performance Graph window: 1. Click on the appropriate Board number to display the board menu. 2. Drag down to Performance Graph... and release. The board-level Performance Graph window will appear. To access the port-level Performance Graph window: 1.

  • Page 54: Configuring The Performance Graph

    Performance Graph will refresh to zero and begin to measure using the new mode. The Performance Graph will now monitor the traffic passing through your IRM2 as a whole or the selected board or port using the user-defined modes. To stop monitoring and to exit the window, click Cancel.

  • Page 55: Chapter 4 Source Address Functions

    IRM2 Source Addressing feature: Find Source Address allows you to detect the specific IRM2 port through which a given MAC address is communicating. Port Locking/Unlocking lets you secure your IRM2 against unknown source addresses trying to access a port.

  • Page 56: Using Port Locking And Unlocking

    When a source address attempts to access a port, the IRM2 will compare that address to those in the Source Address Database for that port. For a station port (one detecting zero...
  • Page 57 There are two ways to determine whether a port’s topology status is currently station or trunk: 1. Bring up that port’s Statistics window, and check the Active Users field. If Active Users is zero or one, the port is in station status; if it is two or more, the port is in trunk status.

  • Page 58: Using Source Addressing

    Source Address Functions You must have superuser (SU) privileges to lock or unlock ports; i.e., the community name entered in the device’s Describe window must provide SU access to the device. NOTE When port locking is enabled, the Locked icon ( View window.

  • Page 59: Setting The Device Ageing Time

    Figure 4-3. Port Source Addresses Window The source address list window displays the MAC addresses of all devices that have transmitted packets through the selected port within a time period less than the SAT’s defined ageing time (addresses that have not transmitted a packet during one complete cycle of the ageing timer are purged).
  • Page 60 Source Address Functions Figure 4-4. Device Ageing Time Window 2. Enter the new Ageing Time in minutes. Allowable times are 1 to 1440. 3. Click window without making any changes. to accept the new Ageing Time, or click Cancel to exit the Using Source Addressing...

  • Page 61: Chapter 5 Alarm Limits

    Disable Board/Disable Port on Alarm option Using the Alarm Limits windows, you can configure alarm limits for the IRM2 at the repeater, board, and port levels; these alarms will notify you — via traps sent to your Enterasys management application’s alarm logging facility —...
  • Page 62 Alarm Limits Figure 5-1. Repeater Alarm Limits Window To access the board-level Alarm Limits window: 1. Click once on the appropriate Board number in the Chassis View to display the board menu will appear. 2. Drag down to Alarm Limits... and release. The Board Alarm Limits window, Figure 5-2, will appear.
  • Page 63 Alarm Limits Figure 5-2. Board Alarm Limits Window To access the port-level Alarm Limits window: 1. Click once on the appropriate Port to display the port menu. 2. Drag down to Alarm Limits... and release. The Port Alarm Limits window, Figure 5-3, will appear.
  • Page 64 When using the Alarm Limits screens to set your alarm thresholds, keep in mind that repeater-level thresholds will apply to all traffic received by the entire IRM2-managed repeater segment; board-level thresholds will apply only to traffic on the selected board; and port-level thresholds will apply to traffic on the specific port.

  • Page 65: Accessing The Alarm Limits Windows

    packets were collisions (15 collisions for every good packet). Therefore, the lower you set your threshold value, the lower the percentage of collisions per good packet you are allowing. Remember, a repeater-level alarm will calculate the number of collisions per good packet based on all traffic received on the repeater channel;...

  • Page 66: Configuring Alarms

    Alarm Limits OOW Collisions Giants within: This field displays the user-configurable alarm limit timer interval: the amount of time the selected statistics will be counted before being compared to the configured thresholds. The allowable values are 10 seconds to 23 hours/59 minutes/59 seconds.

  • Page 67: Setting Alarm Limits

    2. Highlight the hour text box (the first box to the left). 3. Click on the up and down arrows to change the time, or type in the new hour time interval. 4. Repeat steps 2 and 3 to set the minutes and seconds of your new time interval.
  • Page 68 Alarm Limits 5. Repeat steps 1-4 for each type of alarm you wish to configure. 6. Click on window. Be sure to click on changes will not be saved. Your Alarm Limits are now set. Any condition that exceeds these alarm limits will generate an alarm, and disable that board or port, if so configured.

  • Page 69: Chapter 6 Trap Selection

    User’s Guide for more details.) In order for your device to issue any traps — and in order for your management workstation to receive those traps — your IRM2’s trap table must have been properly NOTE configured via Local Management; see the IRM2 hardware manual or Local Management documentation for more information.

  • Page 70: Trap Definitions

    Trap Selection 2. Drag down to Trap Selection... and release. The Repeater Trap Selection window, At the repeater level, a check box indicates the state of settings for all ports that are on the device. The check box will be: Checked —...
  • Page 71 Information included in a Segmentation trap will include the hub number and port number associated with the trap. Source Address Traps The IRM2 can issue several different traps in response to changes in a port’s Source Address Table: A newSourceAddress trap is generated when a station port — one receiving packets from no source addresses, or from a single source address —...

  • Page 72: Configuring Traps

    Although you can change a check box to gray to indicate a “No SET” state, there is no practical reason to do so. To enable or disable the above-described traps at all ports on your IRM2: 1. Open the Repeater Trap Selection window.

  • Page 73: Chapter 7 Redundancy

    (or subsequent backup) link fail. The IRM2 monitors the link status of the primary port for each redundant circuit by polling the physical addresses of designated nodes on the circuit using an Enterasys proprietary poll.
  • Page 74 Figure 7-1. Redundancy Configuration Window Figure 7-2. Chassis View in Redundancy Mode The Redundancy Configuration window, redundant circuit for your IRM2, as well as Rename, Reset, Enable, Disable, or reconfigure the Retry Count for any circuits you have configured. The altered Chassis View display, assign primary and backup ports to each circuit.

  • Page 75: Establishing Redundancy

    • Specifying all ports on the selected IRM2 that will act as network links for the circuit • Assigning a priority to each port (primary or backup) •...

  • Page 76: Entering The Physical Addresses Of Devices To Be Polled

    The IRM2 will simultaneously poll all addresses on each circuit’s list; if it cannot establish a link with any address on the list after the designated number of retries, the IRM2 assumes the circuit is down and switches traffic to a designated backup port.

  • Page 77: Assigning Backup Ports And Port Priority To The Circuit

    Each circuit contains one primary port and several additional ports that serve as backups. If the primary port fails, the redundancy path will switch to the first backup port specified, and as necessary, switch to subsequent backup ports in the order in which they were specified.

  • Page 78: Setting The Polling Interval And Number Of Retries

    If at least one reply is received during the polling interval, the IRM2 simply polls all addresses again at the end of the interval. If no reply is received during the polling interval, the IRM2 will continue polling for the number of retries set for each circuit;...

  • Page 79: Activating The Circuit

    If you are polling devices that are some distance from the IRM2, or if your network is somewhat slow, be sure to set your polling interval and/or number of retries accordingly NOTE to avoid the unnecessary use of backup ports.

  • Page 80: Testing The Circuits

    Redundancy Be sure to physically connect your backup ports once your redundant circuit has been enabled! CAUTION To disable a circuit: 1. Use the drop-down list to display the appropriate circuit in the Current Circuit text box; note that the current status of the selected circuit (enabled or disabled) is displayed just below the Current Circuit text box.

  • Page 81: Reconfiguring A Circuit

    To establish a daily time of day for a test: 1. In the upper right hand corner of the Redundancy Configuration window, click on the gray box to the right of the Test Time of Day text box. The Test Time of Day window, 2.

  • Page 82: Changing Port Status

    Redundancy Redundancy will no longer be in effect for that circuit, and you can now reconfigure and re-enable it. If you disable a circuit with no plans to re-enable it, remember that all configured backup ports will remain disabled by management until they are manually re-enabled using the port menus from the Chassis View window (in Logical display mode).

  • Page 83: Resetting A Circuit

    Any backup port which has been part of an enabled circuit will remain disabled by management until you turn it back on at the Chassis View window (in Logical mode), so NOTE that accidental data loops do not occur. Be sure to disconnect any redundant network links before re-enabling ports.
  • Page 84 Redundancy 2. If you select Yes, all circuits will be reset to their initial default status, regardless of whether they are currently enabled or disabled. If you select No, circuits will remain in their current condition. Any backup port which has been part of an enabled redundant circuit will remain disabled by management until you turn it back on at the Chassis View window (in Logical mode), so that accidental data loops do not occur.

  • Page 85: Index

    Active link status 7-4 Active Users 1-5, 3-3 Add Poll Address window 7-4 Admin 2-9, 2-10 Admin/Link 2-9 Ageing Time 4-5 setting 4-5 alarm limit timer interval 5-6 alarm limits 2-18 Alignment Errors 5-5 Alignment errors 3-4 Allow Port to be Disabled on Alarm 5-7 Board Menus 2-7 Board Name 1-5 board name 2-17...
  • Page 86 I/F Summary window 2-19 Interface Detail window 2-21 testing or disabling an interface 2-24 Interface Group window 2-21 Interface Statistics window 2-21 IP address 1-5, 2-3 IRM2 1-1 Link 2-9, 2-10 Link State Traps 6-1 LNK (Linked) 2-10 Load 2-20 Location 1-5...
  • Page 87 Soft Errors 3-4 Source Address Traps 6-1 Source Addresses window 4-5 accessing 4-4 sourceAddressTimeout 6-3 Statistics window board level 3-3 port level 3-3 repeater level 3-2 Summary Statistics window 3-7 board level 3-8 configuring 3-9 device level 3-8 Technical support 1-7 Test Time of Day window 7-9 threshold value 5-7 time interval 5-6...
  • Page 88 Index Index-4...
