MicroMMAC-T User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroMMAC-T and is the answer not in the manual?

Questions and answers

Related Manuals for Enterasys MicroMMAC-T

Summary of Contents for Enterasys MicroMMAC-T

  • Page 1 MicroMMAC-T User's Guide...
  • Page 3 100% reliable, we strongly caution you to write protect and then verify that the Licensed Software, prior to installing it, is virus-free with an anti-virus system in which you have confidence. Enterasys Networks makes no representations or warranties to the effect that the Licensed Software is virus-free. Copyright April 2000 by Enterasys Networks.
  • Page 4 AppleTalk, Apple, Macintosh, and TokenTalk are registered trademarks; and Apple Remote Access and EtherTalk are trademarks of Apple Computer, Inc. SmartBoost is a trademark of American Power Conversion ST is a registered trademark and C++ is a trademark of AT&T Banyan and VINES are registered trademarks of Banyan Systems, Inc.
  • Page 5 (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013. Enterasys Networks, 35 Industrial Way, Rochester, New Hampshire 03867-0505. (a) This computer software is submitted with restricted rights. It may not be used, reproduced, or disclosed by the Government except as provided in paragraph (b) of this Notice or as otherwise expressly stated in the contract.

  • Page 7: Table Of Contents

    Related Manuals... 1-3 Software Conventions ... 1-3 Using the Mouse ... 1-3 Using Window Buttons... 1-5 Common MicroMMAC-T Window Fields ... 1-5 Getting Help ... 1 -7 Using On-line Help... 1-7 Getting Help from Enterasys Global Call Center... 1-7 Chapter 2 The MicroMMAC-T Chassis View Viewing Chassis Information ...
  • Page 8 Contents Accessing the UPS Window ... 2-25 Setting the UPS ID ... 2-27 Using the Test Option... 2-27 Using the Disconnect Option ... 2-27 Resetting the Device ... 2-27 Enabling and Disabling Port Mapping ... 2-28 Enabling and Disabling Link Traps... 2-29 Enabling and Disabling Link Traps at the Board Level...
  • Page 9 The Station Statistics Window Performance Fields ... 3-20 The Station Statistics Window Soft Error Fields ... 3-21 The Station Timer Statistics Window ... 3-22 Station Timer Statistics Window Fields... 3-23 Port Performance Graphs ... 3-23 Port Performance Graph Statistics ... 3-24 Configuring the Port Performance Graph ...
  • Page 10 Contents viii...

  • Page 11: Chapter 1 Introduction

    Cabletron’s STH Series non-intelligent Token Ring hubs with one MicroMMAC-T, and the entire stack can be managed by the MicroMMAC-T as a single Token Ring. This configuration allows you to expand the connectivity of the MicroMMAC-T to up to 120 ports.

  • Page 12: Using This Guide

    Enterasys Networks Global Call Center. Chapter 2, The MicroMMAC-T Chassis View, describes the visual display of the MicroMMAC-T’s front panel and explains how to use the mouse within the Chassis View; the operation of several chassis-level management functions —...

  • Page 13: Related Manuals

    Related Manuals The MicroMMAC-T user’s guide is only part of a complete document set designed to provide comprehensive information about the features available to you through NetSight Element Manager. Other guides that include important information related to managing the MicroMMAC-T include: Enterasys’...
  • Page 14 Introduction Left Mouse Button Right Mouse Button For many mouse operations, this document assumes that the left (primary) mouse button is to be used, and references to activating a menu or button will not include instructions about which mouse button to use. However, in instances in which right (secondary) mouse button functionality is available, instructions will explicitly refer to right mouse button usage.

  • Page 15: Using Window Buttons

    Any menu topic followed by ... (three dots) — for example Statistics... — calls up a window or screen associated with that topic. Common MicroMMAC-T Window Fields Similar descriptive information is displayed in boxes at the top of most device-specific windows in NetSight Element Manager, as illustrated in Figure 1-2.
  • Page 16 MAC Address Displays the manufacturer-set MAC address associated with the IP address used to define the MicroMMAC-T icon. This address is factory-set and cannot be altered via NetSight Element Manager. The device’s MAC address may be altered using local management; if so, the locally administered MAC address will appear in this field.

  • Page 17: Getting Help

    NetSight Element Manager. Using On-line Help You can use the MicroMMAC-T window specific to the device. When you click on a Help button, a window will appear that contains context-sensitive on-screen documentation that will assist you in the use of the windows and their associated command and menu options.
  • Page 18 Introduction Netsight_docs@enterasys.com To locate product specific information, refer to the Enterasys Web site: http://www.enterasys.com/. For the highest firmware versions successfully tested with NetSight Element Manager 2.2.1, refer to the Readme file from the NetSight Element Manager program group. If you NOTE have an earlier version of firmware and experience problems, contact the Global Technical Assistance Center.

  • Page 19: Chapter 2 The Micrommac-T Chassis View

    To access the MicroMMAC-T Chassis View window, use one of the following options: 1. In any map, list, or tree view, double-click on the MicroMMAC-T you wish to manage; 1. In any map, list, or tree view, click the left mouse button once to select the MicroMMAC-T you wish to manage.

  • Page 20: Viewing Chassis Information

    The MicroMMAC-T Chassis View Viewing Chassis Information The MicroMMAC-T Chassis View window representation of the MicroMMAC-T’s front panel, including a color-coded port display which immediately informs you of the current configuration and status of all station and ring ports on the device.

  • Page 21: Front Panel Information

    The areas around the main port display provide the following device information: The IP address assigned to the MicroMMAC-T appears in the title bar of the Chassis View window; this field will display the IP address you have used to create the MicroMMAC-T icon.

  • Page 22: Menu Structure

    Menu Structure By clicking on various areas of the MicroMMAC-T Chassis View display, you can access menus with device-, network-, module-, and port-level options, as well as utility applications that apply to the device.
  • Page 23 Figure 2-2. MicroMMAC-T Chassis View Menu Structure Additional menus (e.g., FDDI) and/or menu options may be available from the Chassis View if you have a BRIM installed in the MicroMMAC-T. These menu options are NOTE discussed in the Bridge/Router Interface Module (BRIM) User’s Guide included in your documentation set.

  • Page 24: Selecting A Port Status View

    2-23, for details • System Group..., which allows you to manage the MicroMMAC-T via SNMP MIB II. Refer to the Generic SNMP User’s Guide for further information. • I/F Summary, which lets you view statistics for the traffic processed by each SNMP MIB II interface on your device.
  • Page 25 MicroMMAC-T’s MIB information), Token Ring Security, which allows you to configure security for Cabletron Systems new Dot 5 Token Ring devices (like the MicroMMAC-T), and the RMON utility, a remote monitoring feature that is supported by many of Cabletron Systems’ intelligent devices. These selections are also available from the Utilities menu at the top of the NetSight Element Manager map window.
  • Page 26 About Chassis Manager..., which displays version information for the Chassis Manager application in use. The Module Menus Module menus for each module in the MicroMMAC-T controlled stack displayed in the Chassis View window provide the following selections: • Status..., which updates you on the condition of a selected module. See Viewing Module Status,page •...
  • Page 27 See Additional menus (e.g., FDDI) and/or menu options may be available from the Chassis View if you have a BRIM installed in the MicroMMAC-T. These menu options are NOTE discussed in the Bridge/Router Interface Module (BRIM) User’s Guide included in your documentation set.
  • Page 28 The MicroMMAC-T Chassis View Port status view options are: Load If you choose Load, the port text boxes will display the percentage of network load processed by each port during the last polling interval. This percentage reflects the network load generated by devices connected to the port compared to the theoretical maximum load (4 or 16 Mbits/sec) of a Token Ring network.

  • Page 29: Ring Port Status

    You can view two Port Assignment categories for your ports: • If you select FNB View, the port text boxes will display their current FNB connection status. For single-ring devices like the MicroMMAC-T, the only possible status condition is FNB 1. •...

  • Page 30: The Chassis Manager Window

    Like most networking devices, Cabletron’s devices draw their functionality from a collection of proprietary MIBs and IETF RFCs. In addition, Cabletron’s newer intelligent devices – like the MicroMMAC-T – organize their MIB data into a series of “components.” A MIB component is a logical grouping of MIB data, and each group controls a defined set of objects.

  • Page 31: Device Type

    Figure 2-4. Sample Device Type Window Module Type By selecting the Module Type option from the Module menu on the MicroMMAC-T Chassis View window, you can view a description of the module types in your MicroMMAC-T-controlled HubSTACK. To view a module type: 1.

  • Page 32: Management Station Configuration

    (location), and the delay time between the recording and the reporting of an error. The upper left corner of the window contains the MicroMMAC-T name, location, Physical (MAC) and IP addresses, and uptime. Figure 2-6. The TR Management Station Configuration Window...

  • Page 33: Setting Station Name And Location

    3. Type in the desired management station name. 4. Click on OK. The name will change in the text box, and then at the MicroMMAC-T management station itself. Click on Cancel to close the window. The Station Location text box allows you to assign the management station’s physical drop identifier.

  • Page 34: Specifying Ring Management Functions

    If the beaconing goes away (because it is external to the hub), the MicroMMAC-T enables the Ring In/Out ports at the interval specified in the Retry Interval field for the number of times specified in the # of Ring Port Retries field to see if the beacon condition on the network has cleared.
  • Page 35 MicroMMAC-T management stations will respond when one or more stations stop participating in the ring polling process, which can prevent certain stations from inserting into the ring. When this option is enabled, the MicroMMAC-T will detect ring poll failures and remove the offending stations from the ring. Ring poll failure detection is based on the Neighbor Notification MAC frame (NNI) transmitted by the Active Monitor.

  • Page 36: Viewing Network Information

    You can identify each ring by name using the Network Name field. To access the Network Information window: 1. At the MicroMMAC-T Chassis View window, click on the Network menu selection, then on the Network 1 entry to display the Network menu selections.

  • Page 37: Network Information Window Fields

    MicroMMAC-T, and only those which are part of the MicroMMAC-T’s management domain. Ports Enabled This field indicates the number of ports in the current ring network that are enabled by network management;...

  • Page 38: Viewing Module Status

    Figure 2-10. The Token Ring Board Status Window Token Ring Board Status Window Fields Board Number The HubSTACK Interconnect Bus port number on the MicroMMAC-T occupied by the currently selected module. Speed The ring speed (4 or 16 MBits/sec) for which the module is configured.

  • Page 39: Viewing Ring Port Status

    2. Click on Ring Port Status... The Ring Port Status window will appear. The following section describes the window. Managing the Hub page 2-30, for more information. Automode, (Figure 2-11) updates you on the configuration and ). The Ring Port pull-down menu will appear. The MicroMMAC-T Chassis View Setting Token 2-21...

  • Page 40: Ring Port Status Window Fields

    Displays the port index number and type (Ring In/Ring Out) of the selected ring port. Last Wire Fault This field displays either the last date and time the MicroMMAC-T was reset, or the date and time that a wire fault on the selected port last occurred. Media Type This field allows you to select the media type of the ring port.

  • Page 41: Using The Media Type And Phantom Current Radio Buttons

    1. Click on Device on the Chassis View window menu bar to access the Device menu; drag down to Edit Device Time..., and release. 2. The Device Time change window, Figure 2-12. Device Time Change Window Managing the Hub The MicroMMAC-T Chassis View Figure 2-12, will appear. 2-23...

  • Page 42: Using An Uninterruptable Power Supply (Ups)

    MicroMMAC-T through the appropriate port, and you have correctly set the SET UPS ID field. Do not set the SET UPS ID field unless you have a UPS attached to the MicroMMAC-T, or you will disrupt your use of NetSight Element Manager.

  • Page 43: Accessing The Ups Window

    Test option to initiate a self test of the unit. To access the UPS window: 1. From the MicroMMAC-T Chassis View window, click on Device in the menu bar to access the Device menu. 2. Drag down to UPS..., and release. The UPS window, Managing the Hub Figure 2-14.
  • Page 44 UPS ID Displays the manufacturer and model type code of the UPS attached to the modem port of the MicroMMAC-T. You must assign this type code for the UPS window to be active. (See the type code for your UPS.) The valid type codes are: •...

  • Page 45: Setting The Ups Id

    Test Result text box next to the Test button. Using the Disconnect Option You can disconnect the UPS attached to your MicroMMAC-T through its COM port, as follows: 1. Click on the Disconnect button near the bottom of the UPS window. Your UPS will now be disconnected.

  • Page 46: Enabling And Disabling Port Mapping

    If you wish to insert an analyzer on a ring, be sure you disable Port Mapping on the port you use for insertion; if you don’t, the MicroMMAC-T will detect that a station which is not participating in neighbor notification has been inserted, and will shut down the port.

  • Page 47: Enabling And Disabling Link Traps

    Enabling and Disabling Link Traps Link traps are generated to management stations in the MicroMMAC-T’s Trap Table when stations insert into the ring (i.e., the port status on the MicroMMAC-T changes from ENB to INS) or remove themselves from the ring (i.e., the port status changes from INS to ENB).

  • Page 48: Enabling And Disabling Link Traps At The Board Level

    The MicroMMAC-T Chassis View 3. Click on the Link Trap Enable radio button to activate link traps for the port, or the Link Trap Disable radio button to turn off link traps. 4. Click OK. Link traps for the selected port will now be enabled or disabled as desired.

  • Page 49: Enabling And Disabling Ports

    Enabling and Disabling Ports Enabling and Disabling Station Ports From the Module and Port menus on the MicroMMAC-T Chassis View window, you can enable and disable all station ports on a selected module, as well as individual station ports, respectively.

  • Page 50: Ring Out Enable/Disable

    Ring Out Enable/Disable The MicroMMAC-T gives you the ability to switch the function of a station port to that of a ring-out port using the Ring Out Enable and Ring Out Disable options in the Port menu.
  • Page 51 The MicroMMAC-T Chassis View Figure 2-17. I/F Summary Window The I/F Summary window provides a variety of descriptive information about each interface on your device, as well as statistics which display each interface’s performance. The following descriptive information is provided for each interface:...

  • Page 52: Interface Performance Statistics/Bar Graphs

    The MicroMMAC-T Chassis View Interface Performance Statistics/Bar Graphs The statistical values (and, where available, the accompanying bar graphs) to the right of the interface description fields provide a quick summary of interface performance. You can select the statistical value you want to display and the units...

  • Page 53: Viewing Interface Detail

    2. Click on Detail. The appropriate I/F Statistics window, appear. Viewing I/F Summary Information The MicroMMAC-T Chassis View Packets transmitted, at the request of a higher level protocol, by the device interface to a subnetwork address (both unicast and non-unicast).
  • Page 54 The MicroMMAC-T Chassis View You can also access this information via the I/F Statistics option available on the individual port menus; see Chapter 3, Three informational fields appear in the upper portion of the window: Description Displays the interface description for the currently selected interface: Ethernet.
  • Page 55 The amount of device memory devoted to buffer space, and the traffic level on the target network, determine how large the output packet queue can grow before the MicroMMAC-T will begin to discard packets. Packets Transmitted (Transmit only) Displays the number of packets transmitted by this interface.
  • Page 56 The MicroMMAC-T Chassis View Transmitted Errors /Packets Transmitted To calculate the total number of inbound and outbound discards: Received Discards + Transmitted Discards To calculate the percentage of inbound packets that were discarded: Received Discards /Packets Received To calculate the percentage of outbound packets that were discarded:...

  • Page 57: Chapter 3 Token Ring Statistics

    Token Ring Statistics Using Statistics window features; monitoring ring-level statistics, timer statistics, and performance graphs; monitoring management station statistics; monitoring port-level statistics, timer statistics, and performance graphs NetSight Element Manager provides valuable performance statistics from the Network, Management Station, and Port levels. The statistics windows include ring status information, beacon statistics, error counts, timer statistics, frame size and protocol statistics, and performance graphs.

  • Page 58: Viewing Elapsed, Average, And Peak Activity Levels

    Token Ring Statistics Using these radio buttons, you can choose whether to view the statistics gathered since the MicroMMAC-T was last restarted or (if you are monitoring port-level statistics) since the station was first inserted (Total), during the last polling interval (Delta), or accumulated from zero at a user-defined point (Cumulative).

  • Page 59: Setting The Statistics Poll Interval

    • Peak (Magenta) — Indicates the maximum level of activity over all time intervals since the window was invoked. Statistics displayed in the color-coded strip charts will automatically update within the time interval you have set using the clock symbol at the bottom of the window (See clock symbol).

  • Page 60: Network Level Statistics

    • Protocol Accessing the Network Statistics Selections To access the Network Statistics selections: 1. At the MicroMMAC-T Chassis View window, click on the Network menu selection, then on the Network 1 entry to access the following statistics selections: • Statistics...

  • Page 61: Ring Status Fields

    By using the radio buttons located at the bottom of the Network Statistics window, you can choose whether to view the statistics gathered since the MicroMMAC-T was last started up (Total), counted during the last polling interval (Delta), or accumulated from zero at a user-defined point (Cumulative).

  • Page 62: Beacon Statistics

    Displays the number of times the active monitor has purged the ring since the network was created, or since the MicroMMAC-T was last reset. This includes the purge at the end of the active monitor selection process. The count is not reset when the active monitor changes.
  • Page 63 Token Ring Statistics The first station detecting the data corruption sets the E bit to 1 in the ending delimiter of the frame and logs the error. This prevents other stations from logging the error and isolates the portion of the line which is causing the data corruption.
  • Page 64 Token Ring Statistics Lost Frames Displays the number of lost frame errors detected on the ring. These occur when a station is transmitting and its TRR (Timer, Return to Repeat) timer expires. This timer ensures that the station returns to the data repeat state. Lost frames are usually caused by a station entering or leaving the ring as the frame is circulating –...

  • Page 65: Network Timer Statistics

    Total Errors The sum of all errors currently recorded. Network Timer Statistics You can use the Network Timer Statistics window number of frames, errors, and bytes processed by the ring over a user-defined time interval (allowable time settings are 1 second to 23 hours, 59 minutes, 59 seconds).

  • Page 66: Network Performance Graphs

    Token Ring Statistics Frames Displays the elapsed, average, and peak levels of good frames transmitted on the network. Errors Displays the elapsed, average, and peak levels of errors received by the network. KBytes Displays the elapsed, average, and peak levels of kilobytes processed by the network.

  • Page 67: Network Performance Graph Statistics

    Network Performance Graph Statistics The Network Performance Graph contains the following statistics: Network Events (Red) Total Errors Ring Purges Beacon States Nothing Traffic (Blue) Frames Percent Load Nothing Configuring the Network Performance Graph 1. Using the mouse, click on the Network Events button (with the red square marker to its left).

  • Page 68: The Frame Size Window

    Token Ring Statistics The Frame Size Window At the Frame Size window, on the ring network controlled by your MicroMMAC-T. The frame sizes and corresponding colors are: • <<64 (Red) • 64-127 (Green) • 128-255 (Rose) • 256-511 (Yellow) •...

  • Page 69: Using The Pie And Bar Radio Buttons

    You can use the Pie and Bar radio buttons to switch from the bar graph to the pie chart to view the size of frames passing through the MicroMMAC-T. Both graph types reflect the type of collection you have chosen: Total or Delta. See for a view of the Device Frame Sizes window with a pie chart displayed.

  • Page 70: The Protocol Statistics Window

    Token Ring Statistics The Protocol Statistics Window At the Protocol Statistics window received by the MicroMMAC-T for a given protocol. Figure 3-9. Protocol Statistics Window with Bar Graph You can view statistics for the following protocols (note the corresponding colors): •...

  • Page 71: Using The Pie And Bar Radio Buttons

    To access the Intelligent Module pull-down menu from the MicroMMAC-T Chassis View window: 1. Click on the Device menu selection on the menu bar in the MicroMMAC-T Chassis View. The Device menu will appear. 2. Click to highlight the Mgmt. Station Statistics... selection. The TR Management Station Statistics window will appear.

  • Page 72: Soft Errors Fields

    By using the radio buttons located at the bottom of the TR Management Station Statistics window, you can choose whether to view the statistics gathered since the MicroMMAC-T was last started up (Total), counted during the last polling interval (Delta), or accumulated from zero at a user-defined point (Cumulative).

  • Page 73: Hard Errors Fields

    A.C. Errors The count detected by the management station of frames (Protocol Data Units or PDUs) containing errors in the A or C bits. Abort Sequences The management station’s count of abort sequences detected on the ring, which were issued by ring stations during transmission. Internal Errors The number of recoverable internal errors detected by the management station, indicating a ring station in marginal operating condition.
  • Page 74 Token Ring Statistics Transmitted Beacons Beacon frames are transmitted by ring stations when certain error conditions are detected. These frames notify all ring stations that there is a problem, and causes the stations in the fault domain (the beaconing station and its NAUN) to remove themselves from the ring and perform a loopback test.

  • Page 75: Port Level Statistics

    Accessing the Station Port Menu To access a Station Port menu: In the Chassis View window, click on any inserted station port (i.e. MicroMMAC-T port display. The Station Port menu will appear, offering the following statistics selections: • Statistics...

  • Page 76: The Station Statistics Window General Fields

    Token Ring Statistics Figure 3-11. The Station Statistics Window The Station Statistics Window General Fields The Station Statistics window contains the following fields: Station Name Use this editable field to assign a name to the station attached to the selected port. Location Use this editable field to assign a drop number to the station attached to the selected port.

  • Page 77: The Station Statistics Window Soft Error Fields

    The Station Statistics Window Soft Error Fields The following fields break down soft errors for the selected station. Line Errors The count of line errors detected by the selected station port. This error indicates a non-data bit between the starting and ending delimiters of data, or a frame check sequence error.

  • Page 78: The Station Timer Statistics Window

    Token Ring Statistics Frequency Errors The number of times the selected station has detected that the incoming signal’s frequency differed from the expected frequency by more than allowed. Total Errors The total number of errors accounted for by the selected port. The Station Timer Statistics Window At the Station Timer Statistics window frames, errors, and bytes processed by the selected station port over a...

  • Page 79: Station Timer Statistics Window Fields

    The Timer Statistics chart automatically updates within the time interval you have set. Set the time interval to update information (from 1 second to 23 hours, 59 minutes, 59 seconds) by using the clock symbol at the bottom of the window. Setting the Statistics Poll Station Timer Statistics Window Fields The Timer Statistics window fields display the different network events measured...

  • Page 80: Port Performance Graph Statistics

    Token Ring Statistics Figure 3-13. Station Port Performance Graph The graph has an x axis that indicates the 60 second interval over which charting occurs continuously, while the y axis measures the amount of traffic or errors that are processed by the station port. Using the Total Errors button (with the red square marker to its left) at the bottom of this window, you can choose whether or not to monitor the total errors detected at the station port (its pull-down menu offers Total Errors or Nothing -...

  • Page 81: Configuring The Port Performance Graph

    Traffic (Blue) Frames Percent Load Nothing Configuring the Port Performance Graph 1. Click on the Total Errors button (with the red square marker to its left). The Total Errors pull-down menu will appear. 2. Click on the desired Total Errors mode (Total Errors or Nothing). The mode you have chosen will appear in the button.
  • Page 82 Token Ring Statistics 3-26 Port Level Statistics...

  • Page 83: Chapter 4 Token Ring Alarms

    NetSight Element Manager’s Alarm Log facility. To receive alarms at your NetSight Element Manager station, its IP address must be entered into the MicroMMAC-T’s Trap Table via local management. or the Remote NOTE Administration Tools application. Please refer to the Remote Administration Tools User’s Guide and/or the L ocal Management Guide for your device if you need further...

  • Page 84: Accessing The Alarm Limits Window

    Figure 4-1. The Alarm Limits Window The number of times (since the ring network was created or the MicroMMAC-T was last reset) that the ring’s active monitor can purge the ring (including purges at the end of the active monitor selection process). Note that the ring purge count is not reset when the active monitor changes.

  • Page 85: Ring-Level Station Alarms

    Token Errors Claim Token Lost Frame Frame Count Beacon Ring-Level Station Alarms When you set a ring-level station alarm (using the fields in the section of the window labeled Station Errors), the alarm threshold will be applied to all stations inserted into the currently monitored ring network.

  • Page 86: Setting Ring-Level Alarm Limits

    Token Ring Alarms When the Alarm Limits window is invoked, the Station Errors fields do not present any values. This is because it is possible that station-level alarm limits have been set at NOTE individual stations (via the Station Alarm Limits window) that may differ from those set at other individual stations or at the ring level.

  • Page 87: Station-Level Alarm Limits

    Click on Reset Defaults to restore the default alarm thresholds. Your MicroMMAC-T alarm limits are now set. When an alarm threshold is exceeded, an alarm will be generated. To view a list of the alarms, check NetSight Element Manager’s alarm logging facility.

  • Page 88: Accessing The Station Alarm Limits Window From The Station List

    Token Ring Alarms Accessing the Station Alarm Limits Window from the Station List To access the Station Alarm Limits window via the Station List window: 1. Click to display the Network pull-down menu. 2. In the Network pull-down menu, click on the Network 1 entry, then drag right and down to select Station List.

  • Page 89: Setting Station-Level Alarm Limits

    Figure 4-2. The Station Alarm Limits Window Setting Station-Level Alarm Limits To set an alarm for an individual station on the ring: 1. Place the text cursor into the desired alarm event field, and type in the threshold value. 2. To enable an alarm, click on the checkbox next to the desired alarm event field.
  • Page 90 Token Ring Alarms Your station alarm limits are now set. When an alarm threshold is exceeded, an alarm will be generated. To view a list of the alarms, check NetSight Element Manager’s alarm logging facility. Refer to the Alarm and Event Handling User’s Guide for more information on viewing the alarm logging facility.

  • Page 91: Chapter 5 The Station List And Station Map

    The Station List Window At the MicroMMAC-T Station List window station on the ring network supported by the MicroMMAC-T (including stations physically attached to another device that are on the ring) in ring order starting from the MicroMMAC-T’s management station. Using this window, you can view statistics for each station on the monitored ring, as well as temporarily remove a station port from the ring network, and set alarm limits for individual stations.

  • Page 92: Station List Window Fields

    The Station List and Station Map Station List Window Fields The Station List window contains the following fields: General Fields Active Monitor The physical address of the current active monitor on the ring you are monitoring. Note this address always displays in Canonical format. Number of Nodes/Stations The number of stations inserted into the ring that you are monitoring.

  • Page 93: Station Fields

    Statistics chapter of this guide. Board The board index to which the station is attached. If a station is not attached to the MicroMMAC-T, this field will list “unknown,” since no link is detected to the MicroMMAC-T itself. Port The port index into which the station is inserted. Note that if the station is not attached to the MicroMMAC-T, this field will list “unknown,”...

  • Page 94: Viewing Station Timer Statistics

    For a complete explanation of this window, refer to The Station Timer Statistics Window, in the Token Ring Statistics chapter of this guide. Note that you can also view Timer Statistics for the MicroMMAC-T Management Station via this method. Removing a Station from the Ring When you use the Remove radio button, the MicroMMAC-T sends a Remove MAC Frame to the selected station.

  • Page 95: Viewing The Station Port Performance Graph

    To invoke the Station Alarm Limits window: 1. Click on the Alarm Limits radio button at the bottom left of the window. 2. Double-click on the station for which you want to set the alarm limits. The station will be highlighted to show it is selected. The Station Alarm Limits window will appear.

  • Page 96: Resetting Counters

    Resetting the counters effectively “wipes” the error history of the MicroMMAC-T since it was last reset. Be aware of others monitoring the ring.

  • Page 97: Station Map Window Fields

    (e.g., a station removing itself from or inserting into the ring). To access the Station Map, select Station Map... from the Network menu on the MicroMMAC-T Chassis View window. The Station Map window will appear. Station Map Window Fields Active Monitor Indicates the physical address of the Active Monitor on the ring.

  • Page 98: Viewing The Station Map

    The selected MicroMMAC-T is initially presented in one of two positions. • If the entire ring fits in the display panel, the MicroMMAC-T is represented by the topmost (12 o’ clock) station square. •...
  • Page 99 3. To position the station text box in the ring map, drag the mouse while depressing the left button. The station text box will reposition in the panel in relation to the cursor drag. Once you position the station text box as desired, release the left button to fix it in place.

  • Page 100: The Station Command Menu

    Click on this option to remove the selected station from the ring so that it can perform a loopback test. When you click this button, the MicroMMAC-T sends a Remove MAC Frame to the selected station. Upon receiving this frame, the station will perform a loopback test to verify that its MAC adapter is functioning correctly.

  • Page 101: Manipulating The Station Map

    Manipulating the Station Map You can manipulate the station map by magnifying portions of the map, rotating the ring, or resizing the map window. Magnifying a Portion of the Map In a ring with many stations, you may want to magnify portions of the map to facilitate working with individual station text boxes or command menus.
  • Page 102 The Station List and Station Map Rotating the Station Map You can use the scroll bar to rotate the station map, as follows and as illustrated in Figure 5-5: Figure 5-5. Using the Scroll Bar to Rotate the Ring Scroll Bar Up Arrow Scroll Bar Down Arrow Scroll Box Page Up...
  • Page 103 The Station List and Station Map Resizing the Station Map Window You can resize the Station Map window just like any other window, by moving the cursor to the window’s boundary (the cursor will display as a two-headed arrow), depressing the left mouse button, and dragging to shrink or expand the window.
  • Page 104 The Station List and Station Map 5-14 The Station Map...
  • Page 105 Chassis Manager Window 2-12 Claim Tokens 4-3 color codes 2-11 color-coded port display 2-2 color-coded strip charts 5-5 command buttons 1-5 Common MicroMMAC-T Window Fields 1-5 Congestion Errors 3-8, 3-17, 3-21 Connection Status 2-3 Date 2-4 device date 2-24 device front panel 2-1...
  • Page 106 Index F.C. Errors 3-8, 3-21 FC Errors 3-17 Firmware, revision 2-3 FNB View 2-11 Frame Check Sequence (FCS) 3-6 Frame Copied Indicator (FCI) 3-7 Frame Count 4-3 Frame Size Window 3-12 Frames 3-10, 3-23 Frequency Errors 3-8, 3-17, 3-22 GETTING HELP 1-7 Hand Cursor 2-2 Hard Errors 3-17, 3-18 Hardware Types 2-12...
  • Page 107 OFF 2-10 OK button 1-5 ON 2-10 On-line Help 1-7 Packets Received 2-37 Packets Transmitted 2-37 Phantom Current 2-22 Physical Status 2-33 pie chart 3-13, 3-15 Port 2-22, 5-3 Port Assignment 2-11 port display, color codes 2-2 Port Level Statistics 3-19 Port Map 2-28 Port Menus 2-8 Port Performance Graphs 3-23...
  • Page 108 Index TRR (Timer, Return to Repeat) 3-8 TVX (Timer, Valid Transmission) 3-8 Unicast 2-36 Unit Failed 2-26 Unit in test... 2-26 Unit OK 2-26 Unknown Protocol 2-37 Up 5-9 Up Time 2-33 UPS ID 2-26 UPS Uptime 2-26 UpTime 2-3 Utilities Menu 2-7 Viewing the Station Map 5-8 Wrapped 2-11...
