Token Ring Statistics

The Station Statistics Window General Fields

The Station Statistics window contains the following fields:
Station Name
Use this editable field to assign a name to the station attached to the selected port.
Location
Use this editable field to assign a drop number to the station attached to the
selected port.
Link Time
The length of time (in days, hours, minutes, and seconds) that the selected station
has been inserted into the ring.

The Station Statistics Window Performance Fields

The following fields give general performance information for the selected
station.
Total Frames
The total number of frames transmitted by the selected station port since its
attached station inserted into the ring.
Total KBytes
The total number of kilobytes transmitted by the selected station port since its
attached station inserted into the ring.
3-20
Figure 3-11. The Station Statistics Window
Port Level Statistics
