HP Compaq MultiSeat ms6000 Hardware Reference Manual page 50

Table A-1 Specifications (continued)
Power Supply
Operating Voltage Range (STD PS)
Operating Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Voltage Range (STD PS)
Rated Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Line Frequency
Power Output
Rated Input Current (maximum)
STD PS
EPA 87/89/85% @ 20/50/100% load PS
1 This system utilizes an active power factor corrected power supply. This allows the system to pass the CE mark requirements
for use in the countries of the European Union. The active power factor corrected power supply also has the added benefit of
not requiring an input voltage range select switch.
44 Appendix A Specifications
1
115V 230V
90-264 VAC 90-264 VAC
90-264 VAC 90-264 VAC
100-240 VAC 100-240 VAC
100-240 VAC 100-240 VAC
50-60 Hz 50-60 Hz
240W 240W
4A @ 100 VAC 2A @ 230 VAC
4A @ 100 VAC 2A @ 230 VAC
ENWW
