14. Rotate the drive cage back down to its normal position.
CAUTION:
Figure 2-28
15. Replace the access panel.
16. If the computer was on a stand, replace the stand.
17. Reconnect the power cord and turn on the computer.
18. Lock any security devices that were disengaged when the access panel was removed.
The system automatically recognizes the drive and reconfigures the computer.

Removing an External 3.5-inch Drive

CAUTION:
computer.
The 3.5-inch drive is located underneath the 5.25-inch drive. You must remove the external 5.25-inch
drive before removing the external 3.5-inch drive.
1. Follow the procedure in
drive and access the 3.5-inch drive.
CAUTION:
the electrical outlet before proceeding.
32 Chapter 2 Hardware Upgrades
Be careful not to pinch any cables or wires when rotating the drive cage down.
Rotating the Drive Cage Down
All removable media should be taken out of a drive before removing the drive from the
Removing an External 5.25-inch Drive on page 27
Ensure that the computer is turned off and that the power cord is disconnected from
to remove the 5.25-inch
