Figure 5-1 de Command Output
Table 5-1 Ready Bit States
Ready Bit State
True
False

LED Indicators

The server has LEDs that indicate the health of the server. This section defines those LEDs.

Front Panel LEDs

There are seven LEDs located on the front panel.
Table 5-2.
Figure 5-2 Front Panel with LED Indicators
MP:>CM DE command status
RDY (upper case)
rdy (lower case)
Meaning
All cell VRMs installed, and both cell latches are locked.
One or more VRMs not installed or failed, and/or one or
more cell latches not locked.
Figure 5-2 shows the front panel LEDs, and
LED Indicators 69
