Korg X5DR AI2 SYNTHESIS MODULE Owner's Manual page 165

Reference Guide
2B External Out Select: This parameter determines whether the X5DR data (output when you
operate the controls on the panel) is transmitted from MIDI OUT or TO HOST connector.
Select "MIDI" to transmit the X5DR data to an external MIDI device with its MIDI IN connected
to the MIDI OUT connector on the X5DR. Select "PCIF" to output data to a computer connected
to the TO HOST connector on the X5DR.
The X5DR receives data input at MIDI IN or TO HOST regardless of this parameter setting.
2C Program Change Filter:
When DIS is selected, MIDI Program Change messages are neither sent nor received.
When ENA is selected, MIDI Program Change messages received on the Global MIDI Channel
select Programs in Program mode, and Combinations in Combination mode. MIDI Bank Select
messages select banks in the selected mode. In Combination mode, MIDI Program Change
messages received on other channels select Programs for corresponding Timbres. If the Global
MIDI Channel and a Timbre's MIDI Channel are set the same, the Global MIDI Channel has
priority and a Combination will be selected. In Multi mode, MIDI Program Change messages
select Programs on tracks set to the corresponding MIDI Channel.
When PRG is selected, MIDI Program Change messages received on the Global MIDI Channel
select Programs in Program mode, but in Combination mode they select Timbre Programs. MIDI
Bank Select messages select banks in the selected mode.
When NUM is selected, operation is basically the same as for ENA except that MIDI Bank Select
messages are ignored.
The following table shows the Program Change and Bank Select receive conditions.
Mode
Program Play
Combination Play
Combination Play
MULTI
X — Not received
q
— Program Change received only
O — Program Change and Bank Select received
With the ENA or PRG setting, changing Programs in Program play mode will cause Program
Change and Bank Select messages to be transmitted. Changing Combinations in Combination
Play mode will cause only Program Change messages to be transmitted.
After Touch Filter: When this is set to DIS, After Touch messages are not received. The X5DR
uses Channel After Touch only, not Polyphonic After Touch.
2D MIDI Controller filter: When the MIDI Controller filter is set to DIS, MIDI Controller messages
such as Pitch Bend, Pitch modulation, and Volume are not received by the X5DR.
MIDI System Exclusive Filter: When the MIDI System Exclusive Filter is set to DIS, System
Exclusive data for parameter editing is neither sent nor received by the X5DR. Normally, this
should be set to DIS, however, when using an X5DR editing program on a personal computer, set
it to ENA.
By connecting the MIDI OUT of one X5DR to the MIDI IN of another X5DR, and setting both
System Exclusive filters to ENA, both X5DR's can be edited simultaneously.
Set this parameter to ENA so that the X5DR will receive the dump data.
However, if 4A MIDI DUMP is selected and shown on the screen, the X5DR receives MIDI Dump
data through MIDI System Exclusive messages even with this parameter set to "DIS."
152
Program No.
Combination No.
Timbre Program No.
Track Program No.
DIS ENA PRG NUM
X O O q
X X
q q
X O O
q
X O O q
