Structure of Multi Mode

Multi mode allows you to use the X5DR as a GM tone generator which conforms to General MIDI
System Level 1.
When GM ON messages are received or when the power is turned on, the GM settings are
automatically selected. You can restore the GM settings in 23A SET TO GM (see page 114). When
the GM settings are selected, MIDI Channels for Tracks 1–16 will become 1–16, respectively.
Track 10 (MIDI Channel 10) is used for a rhythm part:G129:GM Kit. Other tracks are assigned
G01: Piano.
You can play different Track Programs on each track by transmitting performance information via
the MIDI channel that corresponds to each track from a computer or sequencer.
External sequencer
or computer

Selecting a Track Program From a Computer or Sequencer

Send the Program Change message on the MIDI channel that corresponds to each track from a
connected computer or sequencer to select Track Programs.
To change Program Banks, send Control Change Bank Select (Controller 0/32). The X5DR will
select a new Program when it receives a Program Change message following a Bank Select
message.
Program Bank
Bank A (A00–A99)
Bank G (G01–128)
Drum Program (G129–136)
The following Programs G01–128 are different than Programs G129–136 in terms of their
response to Bank Select messages.
Program numbers used to select a Drum Program (G129–136) in the Drum Program Bank:
Drum Program
G129
G130
G131
G132
• Transmit functions and operations for Bank Select messages and Program numbers are
different depending on the type of connected sequencer or sequence software. Refer to your
sequencer or sequence software manual for detailed operational information.
Default setting for GM MIDI Channel
MIDI Channel
1 Track 1 Program G01
2 Track 2 Program G01
3 Track 3 Program G01
4 Track 4 Program G01
5 Track 5 Program G01
6 Track 6 Program G01
7 Track 7 Program G01
8 Track 8 Program G01
9 Track 9 Program G01
10 Track 10 Drum Program G129
11 Track 11 Program G01
12 Track 12 Program G01
13 Track 13 Program G01
14 Track 14 Program G01
15 Track 15 Program G01
16 Track 16 Program G01
MIDI Bank Select
CTRL#0=0 CTRL#32=0
CTRL#0=56 CTRL#32=any number
CTRL#0=62 CTRL#32=any number
Program Number Drum Program
0 G133
16 G134
25 G135
32 G136
Start-up Guide
Effect
L/MONO
units R
Program Number
40
64
24
48
Using a
Computer/
Sequencer
17
