Stereo Delay

These effects create stereo delay patterns in which you can set the left and right delay times
independently. Using the High Damp parameter, you can make delays decay in a natural way.
13: Stereo Delay
This is a stereo delay effect with feedback.
The delay time can be set independently for
the left and right channels.
The high damp parameter can be used to
produce a more natural echo effect by
gradually attenuating the high frequencies of
successive delay repeats.
14: Cross Delay
This is a stereo delay effect with independent
delay parameters for the left and right
channels. The delay outputs are crossed over,
and each delay receives the other delay's
feedback signal. Thus, the delay repeats
appear to move between the left and right
outputs.
17A StereoDly ø
D.TimeL=250 R260
17A
LCD Parameter
Delay Time Left
(D.Time L)
17A
Delay Time Right (R)
Feedback (FB)
17B
High Damp (H.Dmp)
EQ Low (EQ.L)
17C
EQ High (H)
For effects 13 and 14, dynamic modulation (16C) can be used to control the DRY:EFF balance.
The EQ part of these effects is active even when the Effect is switched off (16A). To bypass these
effects completely, select 0:No Effect.
17B StereoDly ø 17C SterepDly
FB+40 H.Dmp30 EQ.L+00dB H=00dB
17B
Range
0–500 ms
0–500 ms
–99...+99%
0–99%
–12...+12 dB
–12...+12 dB
Left
EQ
Feedback
Delay L
Delay R
Right
Feedback
EQ
Left
EQ
Feedback
Delay L
Delay R
Feedback
Right
EQ
ø
17C
Description
Delay time for the left channel
Delay time for the right channel
The amount of delay signal that is fed back into the effect.
Minus values invert the feedback signal phase
High frequency decay
0 = bright delay
99 = dark delay
Low EQ cut and boost
High EQ cut and boost
Reference Guide
Mix
4
Effect
Parameters
Mix
Mix
Mix
123
