Korg X5DR AI2 SYNTHESIS MODULE Owner's Manual page 118

7A, 7B Panpot
These parameters allow you to pan the output of each Timbre between buses A and B. These buses
feed the effects processors. See "20A–20B Effect Placement" on page 117.
Timbres 1–4
07A PANPOT 1-4 ø
A12 PRG B 9 CNT
7A
LCD Parameter
7A Timbre 1~4 Panpot
7B Timbre 5~8 Panpot
OFF: Nothing is output to buses A and B.
A15–CNT–B15: You can set different output levels for buses A and B. For a setting of A15,
Timbre output is to bus A only. For a setting of B15, to bus B only. And for a setting of CNT,
equally to buses A and B. The Pan setting for each Oscillator set in Program Edit mode is ignored,
and both Oscillator 1 and Oscillator 2 will use the Pan setting determined here.
PRG: When this setting is selected, the pan settings that have been set for a Program in Program
Edit mode are used. See "1A–1D Oscillator1 Setup" on page 80 and "2A–2F Oscillator2 Setup"
on page 82.
If a Program is using a drum kit, the pan settings for each drum sound will be used when PRG is
selected. See "6A–6D Drum Kit1 Setup" on page 158 and "7A–7D Drum Kit2 Setup" on
page 160.
For a setting other than OFF or PRG, these parameters can be controlled using MIDI Pan
Controller No. 10. See "MIDI Panpot, Send Data" on page 173 for details about the relationship
between pan value and MIDI Controller value.
8A, 8B Send C & Send D
These parameters allow you to set the output level of each Timbre sent to buses C and D. These
buses feed the effects processors. See "20A–20B Effect Placement" on page 117.
Timbres 1–4
08A SENDCD 1-4 ø
9:0 0:9 5:5 5:5
8A
LCD Parameter
Timbre 1~4 Send C
8A
Timbre 1~4 Send D
Timbre 5~8 Send C
8B
Timbre 5~8 Send D
0–9: When a Program is used in a Combination, its Send C and Send D parameters are ignored,
and these settings are active. Oscillators 1 and 2 use the same settings. Likewise, when the
Program is set to DRUM mode, the Send C and Send D settings of the individual drums within
the kit are ignored, and these settings are active.
P: When this setting is selected, the Send C and Send D settings that have been set for a Program
in Program Edit mode are used. See "1A–1D Oscillator1 Setup" on page 80 and "2A–2F
Oscillator2 Setup" on page 82. If a Program is using a drum kit, the settings for each drum sound
will be used. See "6A–6D Drum Kit1 Setup" on page 158 and "7A–7D Drum Kit2 Setup" on
page 160.
For settings from 0–9, the Send C parameters can be controlled using MIDI Reverb Level
Controller No. 91. MIDI Chorus Level Controller No. 93 can be used to control Send D.
Timbres 5–8
ø
07B PANPOT 5-8
PRG CNT PRG PRG
7B
Range
OFF, A15–CNT–B15,
PRG
Timbres 5–8
ø
08B SENDCD 5-8
5:5 5:5 0:0 P:P
8B
Range
0–9, P
Description
Pans the outputs of each Timbre between buses A and
B
Description
Sets the output level of each Timbre sent to buses C
and D
