Power Supply Unit Load Requirements
Power Supply Unit Load
Requirements

Unit Load Rating of System Modules

Module
008
008 MLX
008 OPT
012 T/R
016 ETR
016 T/R
100D (DS1)
400 GS/LS/TTR
2
400 (LS)
400EM
1 012 modules older than 517H13 may have a unit load up to 8.4.
2 This is a MERLIN II loop-start-only module that can be used in the MERLIN
LEGEND Communications System.
—Continued
Unit Load
12.0
13.5
8.0
1
7.2
24
12.8
0.0
0.0
0.0
8.0
Module
408 GS/LS
408 GS/LS-ID-MLX
408 (LS)
412 LS/ETR
800 GS/LS
800 GS/LS-ID
2
800 (LS)
800 DID
800 NI-BRI
Processor
April 1999
Unit Load
12.0
12.0
12.0
18
0.0
0.0
0.0
8.0
0.0
0.0
